3D Gyratory Rockers - SSM3, SSL3 Stuart

Specification

Model

SSM3

SSL3

Rocking action

3D gyratory

3D gyratory

Platform dimensions ( w x l )

235 x 235 mm

355 x 355 mm

Speed range

5 to 70 rpm

5 to 70 rpm

Angle of tilt

3 to 12°

3 to 12°

Angle adjustable

Yes by hand

Yes by hand

Maximum load

3 kg

10 kg

Overall dimensions ( w x d x h )

240 x 300 x 150

360 x 420 x 170

Tier height, mm

125/tier

125/tier

Operational temp. range

+4 to +40°C

+4 to +40°C

Max. permissible humidity

80%

80%

Net weight

5 kg

10 kg

Electrical supply

230 V, 50 Hz, 50 W

230 V, 50 Hz, 50 W

Ordering Information

Model

Description

SSM3

Rocker, see-saw, mini

SSL3

Rocker, gyratory, lab scale

SSM3/1

Tier system ( 2 platforms plus 8 bars ) fits SSM3

SSL3/1

SSL3/1 Tier system ( 2 platforms plus 8 bars ) fits SSL3
