Advanced Microwave Optics System WA-9316A Pasco Scientific |
|||
|
Features |
|||
|
Diffraction Slit Hardware |
Spacers and holders for performing interference experiments |
||
|
Ethafoam® Prism with Styrene Pellets |
Used for refraction of microwaves. The index of refraction of styrene is determined |
||
|
Rotating Mounts |
The transmitter and receiver rotate through a full 360° ( an important feature for polarization experiments ) |
||
|
Gunn Diode Transmitter |
A stable, low-voltage source of linearly polarized microwaves ( 10.5 GHz; 15 mW ) |
||
|
18 cm High Mounts |
Minimize tabletop reflections for improved accuracy |
||
|
Receiver with a Built-in Amplifier |
Variable sensitivity ensures clear data, even for low-intensity measurements ( Bragg diffraction and Brewster's angle ) |
||
|
Long-Arm Goniometer |
For easy setup and alignment. The built-in degree and millimeter scales ensure accurate measurements |
||
|
Magnetic Mounting |
All components mount magnetically. Setup is quick and accurate |
||
|
Durable Construction |
Parts are made of stainless steel or die-cast aluminum |
||
|
Includes |
|||
|
Description |
Microwave Optics : Basic System |
Advanced Microwave Optics System |
Microwave Accessory Package |
|
WA-9314C |
WA-9316A |
WA-9315 |
|
|
Gunn Diode Transmitter with mounting stand |
● |
● |
|
|
Receiver with built-in amplifier and mounting stand |
● |
● |
|
|
Goniometer with fixed and rotatable arms and degree scale |
● |
● |
|
|
Fixed-arm assembly for interferometer experiments |
● |
● |
|
|
Component holders: two standard, one rotating |
● |
● |
|
|
Rotating table |
● |
● |
|
|
Reflectors : two full reflectors ( metal ), two partial reflectors ( wood ) |
● |
● |
|
|
Polarizers ( two ) |
● |
● |
|
|
Diffraction slit hardware ( holders and spacers ) |
● |
● |
|
|
Prism ( Ethafoam ) with styrene pellets |
● |
● |
|
|
AC adapter |
● |
● |
|
|
Laboratory manual with 12 ready-to-use experiments |
● |
● |
|
|
An explanation of the physical principles with all relevant equations |
● |
● |
|
|
Illustrations for easy setup |
● |
● |
|
|
Step-by-step instructions |
● |
● |
|
|
Questions and data tables in a worksheet format |
● |
● |
|
|
Teacher's guide with answers and typical results |
● |
● |
|
|
Simulated Crystal Lattice |
|
● |
● |
|
Polyethylene Panel |
|
● |
● |
