Alat Ukur Kadar Lemak Daging MFM-992 and MFM-1092
Sensor
Type	Microstrip transmission line.
Microwave Frequency	2.0 Ghz ( +/- 20 Mhz )
Microwave Power	2 Milliwatts
Materials	Stainless steel, PTFE
Display
Type	LCD, 2 lines x 12 characters
Sensor Enclosure
Material	ABS Plastic. Waterproofed to IP 65.
Size	195 mm x 100 mm x 40 mm.
Weight ( Incl Batteries )	725 gms.
Hardware / Software
Microprocessor	Operations controlled by new microprocessor.
Memory	Up to 80 Calibrations can be programmed in each meter.
PC Interface	Stored data sets can be transferred to PC, via data cable supplied… both in “real time”, and as “historic data”.
Software	Data Management Software packages are supplied with each meter.
Batteries
	Powered by internal rechargeable batteries, Nickel metal Hydride ( NiMh )
Charger / Power Supply
	Universal charger / power supply. Also acts as desktop power supply unit.
Input voltage	110 V AC, 50 – 60 Hz
Output voltage	9 V DC, 1.2 A
Accuracy Of Results
The accuracy of the FATMETER depends upon the fat/oil content of the sample being measured and ranges from an uncertainty in the fat content of ( +/- ) 1% ( 95% confidence interval ) at low levels to ( +/- ) 4% at very high levels ( greater than 45% ).
Therefore it is advisable that the operator follows the measurement methodology rigorously, and always takes readings as described in wall charts supplied.
Accuracy Guide
Fat/Oil Reading	Accuracy
2 to 15%	from.. ± 0.5% rising to.. ± 1.0% ( 13 – 15% at 14% )
16 to 30%	from.. ± 1.0% rising to.. ± 2.0% ( 28 – 32% at 30% )
31% and above	from.. > ± 2.0% rising to.. ± 4.0% ( 46 – 54% at 50% )
The results gained will allow the operator to take swift decisions regarding processing of the type of meat being measured.
