Alcoholmeter Precision Alla-France
According to OIML ISO4801 - NF B 35-515
Ethanol by % Vol.
Calibration temperature 20 ºC
Individual number on the scale
Ethanol by % Vol.
Calibration temperature 20 ºC
Individual number on the scale
Technical Specifications
| Range | Unit | Div. | Accuracy | Callibration Temp. | Length ( mm ) | Ref. Item New # | No. Urut |
|---|---|---|---|---|---|---|---|
| 0-10 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC000/20-qp | a |
| 10-20 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC010/20-qp | b |
| 20-30 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC020/20-qp | c |
| 30-40 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC030/20-qp | d |
| 40-50 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC040/20-qp | e |
| 50-60 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC050/20-qp | f |
| 60-70 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC060/20-qp | g |
| 70-80 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC070/20-qp | h |
| 80-90 | % vol | 0.1 | ± 0.1 | 20°C | 350 | 0910FC080/20-qp | i |
| 90-100 | % vol | 0.1 | ± 0.1 | 20 °C | 350 | 0910FC090/20-qp | j |
| 80-100 | % vol | 0.2 | ± 0.2 | 20 °C | 350 |
