ANALEX fdM plus Ferrous Debris Monitor

Product Code

FG-K17144-KW

Specifications

Detection Range

50 ml Bottle 0 - 2500 ppm

10 ml Syringe 0 - 19000 ppm

5 ml Syringe 0 - 34000

5 ml Tube 0 - 28000 ppm

5 ml Grease Pot 0 - 8000 ppm

Fluid Compatibility

Lubes & Greases; can also be used as quantification of Fe contamination in QC samples

Sample Size

50 ml Sample Bottles, 10 ml Syringes, 5 ml Syringes & Test Tubes, 5 ml Grease Pots

Test Time

< 1 minute to stabilise from power on < 15 seconds per sample

Operating Temp

15°C - 40°C ( 60°F - 104°F )

Weight

4.22 kg

Optional Extras & Consumables

Order Code

Tests Included

FG-K17725-KW

Grease Thief Starter Pack & Calibration Standards

BI-K17726

Grease Thief Type 1 Syringe & Cap ( pack of 10 )

MA-K17121-KW

ANALEX fdMplus User Manual ( Grease Thief )

FG-K15004-KW

5 ml Grease Sample Pots with Lids ( pack of 100 )

FG-K15005-KW

5 ml Grease Sample Pots with Lids ( pack of 3000 )
