Analog Overhead Stirrers HS-A Daihan Scientific

Specification

Stirring Capacity & Models

Max. 10 Lit. ( H2O )

Max. 20 Lit. ( H2O )

“HS-50A”

“HS-120A”

Maximum Viscosity

10,000 mPas

50,000 mPas

Maximum Torque

85 Ncm

145 Ncm

Speed Range & Motor

0 ~ 3,000 rpm, Worm - Geared DC Motor

Motor Rating ( Input / Output )

83 / 75 W,  1/10 HP

130 / 120 W,  1/6 HP

Controller

Analog Phase Controller

Max. Impeller Shaft Diameter

8 mm

Permissible Temp. & Humidity

0 ~ 40 ℃,  80 %

Safety Device

Over Heat Protector for motor

Material

ABS and Aluminum

Dimension & Weight

90 × 145 × h180 mm,  4.5 kg

90 × 145 × h180 mm,  5.3 kg

Packing Size & Gross  Weight

320 × 300 × h180 mm,   5 kg

320 × 300 × h180 mm,   8 kg

Power Consumption

85 W

130 W

Power Supply & Cord Plug**

1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
