Analytical Balances HR-250 & HR-250AZ AND

Features

Fast stabilization in 2 seconds

Large removable breeze break with antistatic coating

Compact foot print : 198 mm × 294 mm

Rotary sliding doors requiring no extra space at the rear

Automatic calibration with an internal mass ( HR-AZ )

Clear, reverse-backlit LCD

Fourteen weighing units including a user-programmable unit

GLP/GMP/GCP/ISO compliant output

Counting mode with the Automatic Counting Accuracy Improvement ( ACAI ) function

Percent mode function

Adjustable response characteristics and hold function

Statistical calculation function

Comparator function with buzzer

Auto power on/off function

Underhook function

Density determination function

Built-in rechargeable battery ( optional )

External Input/Output

RS-232C interface

Quick USB interface ( optional )

LAN – Ethernet interface with WinCT-Plus software ( optional )

Options

FXi-02

Quick USB interface with cable

FXi-08

Ethernet interface with WinCT-Plus software

FXi-09

Built-in rechargeable battery

* The FXi-02, FXi-08, and FXi-09 cannot be used at the same time.

Accessories

AD-1651

Vibratory spoon

AD-1683

Static eliminator

AD-1684

Electrostatic field meter

AD-1687

Weighing environment logger

AD-1688

Weighing data logger

AD-1689

Tweezers for calibration weight

AD-8118C

Universal printer

AD-8121B

Compact printer

AD-8526

Serial/Ethernet converter

AD-8527

Quick USB adapter

AD-8920A

Remote display

AD-8922A

Remote controller

AX-FXi-31

Main unit cover ( 5 pcs )

AX-USB-9P

Serial/USB converter

AX-KO2466-200

RS-232C cable ( 9P-9P )

Specifications

Model

HR-250AZ/HR-250A

HR-251AZ/HR-251A

HR-150AZ/HR-150A

HR-100AZ/HR-100A

Weighing capacity

252 g

62 g / 252 g**

152 g

102 g

Minimum weighing value

0.1 mg

0.1 mg / 1 mg

0.1 mg

Repeatability ( Standard deviation )

0 to 200 g : 0.1 mg

0.1 mg / 0.5 mg

0.1 mg

200 to 252 g : 0.2 mg

Linearity

±0.3 mg

±0.3 mg /±1 mg

±0.2 mg

Sensitivity drift ( 10 °C to 30 °C )

±2 ppm/°C

Weighing pan

Ø90 mm

** Smart range function

The minimum weighing value will switch to 1 mg automatically when the display value exceeds 62 g but returns to 0.1 mg by pressing the RE-ZERO ( tare ) key.
