AND ML-50 Moisture Analyzers |
||||
|
Specifications |
||||
|
Model |
MS-70 |
MX-50 |
MF-50 |
ML-50 |
|
Measurement Method |
400W straight halogen lamp heating system with SRA filter and SHS weighing technology |
|||
|
Max Sample Weight Capacity |
71 g |
51 g |
||
|
Weight Resolution |
0.0001 g |
0.001 g |
0.002 g |
0.005 g |
|
Moisture Content Display |
0.001%/0.01%/0.1% |
0.01%/0.1% |
0.05%/0.1%/1% |
0.1%/1% |
|
Moisture Content Accuracy over 1 g |
0.05% |
0.10% |
0.20% |
0.5% |
|
( Standard Deviation ). over 5 g |
0.01% |
0.02% |
0.05% |
0.1% |
|
Heating Technology |
Halogen lamp ( Straight type, 400 Watt max, 5000 hours ) |
|||
|
Drying Temp. ( 1°C increment ) |
30-200°C |
50-200°C |
||
|
Memory of Measurement Programs |
20 sets |
|
10 sets |
5 sets |
|
Measurement Programs |
Standard Mode/Automatic Mode/Quick Mode/Timer Mode/Manual Mode |
|||
|
Measurement Mode |
Moisture content ( Wet or Dry base ) / Dry content/Ratio/Weight |
|||
|
Heating Mode |
Standard/Quick/Step/Ramp |
Standard/Quick |
||
|
Display Type |
Large VFD |
|||
|
Interface |
RS-232C standard |
|||
|
Data Memory Function |
100 |
|
50 |
30 |
|
Operating Temperature |
5-40°C ( 41-104°F ) less than 85% RH |
|||
|
GLP/GMP/ISO |
Available |
|||
|
Self Check Function |
Standard |
|||
|
Communication Software |
WinCT-Moisture standard |
WinCT standard |
||
|
Sample Pan Size |
Ø85 mm |
|||
|
Power |
AC 100V to 120V ( 3 A ) or AC 200V to 240V ( 1.5 A ), 50/60 Hz, Approx. 400 W |
|||
|
Physical Dimention/Weight |
215 ( W ) x 320 ( D ) x 173 ( H ) / Approx. 6 kg |
|||
|
Standard Accessories |
Sample Pans ( 20 for MS/MX/MF 10 for ML ), Pan Handles ( 2 for MS/MX/MF, 1 for ML ), Tweezers ( for MS/MX/MF ), Spoon ( for MS/MX/MF ), Test Sample ( 30 g of Sodium Tartrate Dihydrate for MS/MX/MF ), CD-ROM ( WinCT-Moisture for MS/MX, WinCT for MF ), Glass Fiber Sheet ( for MS/MX/MF ), RS-232C Cable ( for MS/MX ), Display Cover, Dust Cover ( for MS/MX/MF ), Instruction Manual, Quick Reference Card, Power Cable, Fuse |
|||
