Anton Paar DMA 35 Density Meter

Specigications

Measuring range

Density

0 to 3 g/cm³

Temperature

0 to 40 °C ( 32 to 104 °F )

Viscosity

0 up to 1000 mPa·s

Accuracy

Density

0.001 g/cm³*

Temperature

0.2 °C ( 0.4 °F )

Repeatability

Density

0.0005 g/cm³

Temperature

0.1 °C ( 0.2 °F )

Resolution

Density

0.0001 g/cm³

Temperature

0.1 °C ( 0.1 °F )

Sample volume

2 mL

Ambient temperature

-10 to +50 °C ( 14 to 122 °F )**

Interfaces

Bluetooth, RFID

Data storage

1024 measuring results

Operation

Capacitive keys

Protection class

IPX4

Power supply

3 x 1.5 V AA LR06 Mignon alkaline batteries

Dimensions

245 mm x 103 mm x 126 mm ( 96.5 in x 40.6 in x 49.6 in )

Weight ( incl. Batteries )

660 g ( 23 ounces )

Supplied accessories

Mat. No. 165216

1 # pump lever with lock function

Mat. No. 165214

1 # rubber housing DMA 35 measuring cell

Mat. No. 172214

1 # filling tube 180 mm

Mat. No. 172211

1 # adapter Luer ¼" UNF

Mat. No. 58802

10 # syringes 2 mL Luer

Mat. No.181207

1 # instruction manual

Mat. No. 58264

1 # allen key 3 mm DIN 911

Measuring method

Anton Paar oscillating U-tube technology

Special features

· Storage of up to 250 different sample IDs for easy identification of samples, users, measuring locations, etc.

· Storage of up to 30 different measuring methods

· Easy operation via capacitive keys, even when wearing protective gloves

· Both left- and right-hand use

· Backlight for the oscillator for close observation of the sample filling process

· Bluetooth interface for wireless data exchange with PC and printer

· RFID interface for quick sample identification and convenient change of the measuring method by reading allocated RFID tags

Sampling

Hand pump or syringe ( for highly viscous samples )

Adjustment

Factory adjusted; readjustment with deionized water or any other reference fluid possible
