AquaMate 8000 UV-Vis & AquaMate 7000 Vis Spectrophotometer Thermo Scientific

Specifications

Model

AquaMate 8000 UV-Vis Spectrophotometer

AquaMate 7000 Vis Spectrophotometer

Optical Design

Dual beam-internal reference detector

Single beam

Spectral Bandwidth

1.8 nm

5.0 nm

Light Source

Xenon flash lamp

Tungsten-halogen lamp

( Typical Lifetime )

( 5 years )

( 1000 hours )

Detector

Dual silicon photodiodes

Silicon photodiode

Wavelength

Range

190 to 1100 nm

325 to 1100 nm

Accuracy

±1.0 nm

±1.0 nm

Repeatability

±0.5 nm

±0.5 nm

Slew Speed

11,000 nm/min

11,000 nm/min

Scanning Speed

10 to 4,200 nm/min

10 to 4,200 nm/min

Data Interval

0.2, 0.5, 1.0, 2.0, 3.0, 5.0 nm

1.0, 2.0, 3.0, 5.0 nm

Photometric

Measurement Modes

Absorbance, % transmittance, concentration

Absorbance, % transmittance, concentration

Range

-0.5 to 5.0 A ; -1.5 to 125 %T ; ±9999 C

-0.1 to 3.0 A ; -0.3 to 125 %T ; ±9999 C

Linearity

Up to 3.5 A at 260 nm

Up to 3.0 A at 340 nm

Accuracy

±0.005 A at 1.0 A, <0.00025  at 0.0 A

0.5 % or ±0.005 A, whichever is greater up to 2 A

Noise

<0.00050  at 1.0 A, <0.00080  at 2.0 A

<0.001 A at 0.0 A, <0.002 A at 2.0 A

Drift

RMS at 260 nm

Peak-to peak at 340 nm

Stray Light

<0.08 %T at 220 nm and 340 nm,

<0.08 %T at 220 nm and 340 nm,

<0.1 %T at 340 nm and 400 nm,

<0.1 %T at 340 nm and 400 nm,

<1.0 %T at 198 nm

<1.0 %T at 198 nm

Display

Graphical with LCD backlight - 9.7 x 7.1 cm ( 3.8 x 2.8 in )

Graphical with LCD backlight - 9.7 x 7.1 cm ( 3.8 x 2.8 in )

Keypad

Sealed membrane with tactile response keys

Sealed membrane with tactile response keys

Connectivity

USB type A port for USB stick ( front panel ),

USB type A port for USB stick ( front panel ),

USB type B port for computer  ( rear panel ),

USB type B port for computer  ( rear panel ),

USB type A port for printer ( rear panel )

USB type A port for printer ( rear panel )

Dimensions

30 W x 40 D x 25 H cm ( 11.8 x 15.7 x 9.8 in )

30 W x 40 D x 25 H cm ( 11.8 x 15.7 x 9.8 in )

Weight

8.6 kg (19 lb.)

8.6 kg (19 lb.)

Power Requirements

100 to 240 V ; 50 to 60 Hz

100 to 240 V ; 50 to 60 Hz

Order Information

Part Number

Description

AquaMate 8000 UV-Vis Spectrophotometer, includes methods on USB memory stick; 6-position, 3-position and 1-position vial holder turrets; user documentation; dust cover; USB cable; 110 V, 220 V and 240 V power cords

AquaMate 7000 Vis Spectrophotometer, includes methods on USB memory stick; 3-position vial holder turret; user documentation; dust cover; USB cable; 110V, 220 V and 240 V power cords

AQ006C

AquaMate 6-position vial holder turret for six 10 mm square vials

AQ003C

AquaMate 3-position vial holder turret for one 13-25 mm round vial, one
20-50 mm rectangular vial and one 10 mm square vial

AQ001C

AquaMate 1-position vial holder turret for one 10 mm square vial

AQ0USB

AquaMate methods, USB memory stick

AQCHNV

AquaMate power cord with China, Australia, New Zealand plug

AQ240V

AquaMate power cord with 240V UK, Singapore plug

AQ220V

AquaMate power cord with 220V Euro plug

AQ110V

AquaMate power cord with 110V US, Japan plug

AC2V24

24 mm round vials, 12 pack

Note : When ordering AQ8000 or AQ7000 instruments, the reagent chemistries, vials and AQCHNV power cord must be ordered separately
