Autoclave SH-AC-60M; SH-AC-80M; SH-AC-100M; SH-AC-128M SH Scientific

Specification

Model

SH-AC-60M

SH-AC-80M

SH-AC-100M

SH-AC-128M

Temp Range

Max 130 °C ( 266 °F )

Using Press

0.1177 to 0.1274 MPa ( 1.2 to 1.3 kg/㎤ )

Temp Controller

Microprocess Digital P I D Controller

Steriling time

00.00 to 99 Hour 59 Min ( Min Sec ) Selectable

Pressure Gauge

Mechanical type 0 to 0.3 MPa

Sensor

PT-100

Capacity

60 L

80 L

100 L

128 L

Demension Internal,mm

350 Φ × 630 H

400 Φ × 650 H

450 Φ × 650 H

500 Φ × 650 H

( W x D x H ) Inch

13.78 Φ x 24.80 H

15.75 Φ x 25.59 H

17.72 Φ x 25.59 H

19.69 Φ x 25.59 H

Demension External,mm

550 x 680 x 1070

600 × 730 × 1060

650 x 780 x 1150

700 x 830 x 1365

( W x D x H ) Inch

21.65x26.77x42.12

23.62x28.74x41.73

25.59x30.71x45.27

27.56x32.68x53.74

Weight

74 Kg

100 Kg

120 Kg

140 Kg

Material Internal

Stainless Steel

Material External

Steel Plate with Powder Heating Coated

Heater Capacity

3 KW

5 KW

Electrical 120V,50/60 Hz, 1Φ

25.0 A

25.0 A

41.7 A

41.7 A
