Autoclave-Sterilizer SA Gemmy

Portable Autoclave Model SA-232

Specification

Chamber

Stainless steel # 304

Size

230 mm Dia X 410 mm ( D )

Capacity

Appr. 16 liters

Overall

335 x 430 x 600 mm

Design temp.

140 ⁰C

Using pressure and temp.

Unwrapped/Wrapped/ Liquid

122⁰C/ 1.12 kg/cm2

Bench Top Autoclave Model SA-232X

Specification

Chamber

Stainless steel # 304

Size

230 mm Dia X 390 mm ( D )

Capacity

Appr. 16 liters

Overall

501 x 406 x 537 mm

Design temp.

140 Cdeg.

Using pressure and temp.

Unwrapped/Wrapped/ Liquid

115-134 ⁰C/ 0.9 -- 2.1 kg/cm2

High Pressure Steam Horizontal Sterilizer Model TC-612

Specification

Chamber

60 Dia x 120 cm , appr. 339 liters

Power consumption

18 KW

Power source

220V/ 380V, 50/60Hz , 3 phases

Working Temp

121℃- 132 ℃

Bench Top Autoclave Model SA-300MA

Specification

Overall

900 D x 620 W x 489 H (mm)

Chamber Size

∮300 x 570 mm ( D )

Chamber Diameter

∮300 mm

Water capacity per cycle

600 cc

Water capacity of water tank

7000 cc

Chamber capacity

40 liter

Gross weight

68 kg

Power supply

230V 50 / 60 Hz

Temperature display

Digital display

Pressure display

Pressure/vacuum gauge

Program ( function ) display

LED display

Indication

Door Closed, Low water, Over heat, Over pressure display

Power consumption

3000 W / 14 Amp, Heater / 2300 W, dry heater / 600 W vacuum pump / 100 W

Sterilization temp.

121℃ / 135℃

Vertical Steam Autoclave Model HL-341

Specification

Capacity

72 liters

Chamber

350 x 750 mm

Control system

Pressure control

Working temp.

120 - 134 ⁰C

Standard

Manual drying, temp and pressure indicators

Standard accessories

Sterilization basket, tube indicator x 2, shelf x1, hose x 1

Gross Weight

140 kgs
