Bacon Bomb Sample Thief Koehler Instrument |
|||||
|
Test Method |
|||||
|
All Samplers Conform to ASTM D4057 (Formerly ASTM D270), D6074 or ASTM D1265 Spec |
|||||
|
Ordering - Sample Thief |
|||||
|
P/N |
Construction |
Seal |
Outside Dia. |
Overall Length |
Ship Weight |
|
in ( cm ) |
lbs ( kg ) |
||||
|
K27700 |
Plated Brass |
Viton O-ring |
3⅜ (8.6) |
15 5/32 (38.5) |
13 ( 5.9 ) |
|
K27701 * |
SS |
V O-ring |
3⅜ (8.6) |
15 5/32 (38.5) |
13 ( 5.9 ) |
|
K27790 |
P Brass |
V O-ring |
2¾ (7) |
12 1/32 (30.6) |
9 (4.1) |
|
K27795 |
P Brass |
metal Seat |
2¾ (7) |
12 1/32 (30.6) |
9 (4.1) |
|
K27791 |
SS |
V O-ring |
2¾ (7) |
12 1/32 (30.6) |
8 (3.6) |
|
K27792 |
Acrylic |
V O-ring |
2¾ (7) |
12 1/32 (30.6) |
8 (3.6) |
|
K27780 |
P Brass |
V O-ring |
2 5/16 (5.9) |
10 5/32 (25.8) |
5 (2.3) |
|
K27785 |
P Brass |
metal Seat |
2 5/16 (5.9) |
10 5/32 (25.8) |
5 (2.3) |
|
K27781 |
SS |
V O-ring |
2 5/16 (5.9) |
10 5/32 (25.8) |
5 (2.3) |
|
K27782 |
Acrylic |
V O-ring |
2 5/16 (5.9) |
10 5/32 (25.8) |
5 (2.3) |
|
K27770 |
P Brass |
V O-ring |
1⅞ (4.7) |
9 11/16 (24.6) |
4 (1.8) |
|
K27771 |
SS |
V O-ring |
1⅞ (4.7) |
9 11/16 (24.6) |
4 (1.8) |
|
K27772 |
Plexiglass |
Buna N O-ring |
1⅝ (4.01) |
9 11/16 (24.6) |
3 (1.4) |
|
K27760 |
P Brass Slim Model |
V O-ring |
1⅛ (2.8) |
13¼ (33.7) |
3 (1.4) |
|
K27761 |
SS Slim Model |
V O-ring |
1⅛ (2.8) |
13¼ (33.7) |
3 (1.4) |
|
K27762 |
Acrylic Slim Model |
V O-ring |
1⅛ (2.8) |
13¼ (33.7) |
3 (1.4) |
