Barnstead Smart2Pure Water Purification Systems Thermo Scientific |
||||||
|
Model |
Smart2Pure Standard |
Smart2Pure UV |
Smart2Pure UF |
Smart2Pure UV/UF |
||
|
Type 1 Water |
||||||
|
Applications examples |
A A, IC, standard buffer |
HPLC, GC-MS and ICP-MS, TOC Analysis, Trace Analysis |
Microbiology, monoclonal antibodies, Cell Culture |
Molecular biology, PCR, DNA sequencing, electrophoresis, cell culture media |
||
|
Resistivity at 25°C, MΩ.cm |
18,2 |
18,2 |
18,2 |
18,2 |
||
|
Conductivity, µS/cm |
0,055 |
0,055 |
0,055 |
0,055 |
||
|
TOC value , ppb |
05-Okt |
1/5 |
5/10 |
1/5 |
||
|
Bacterial content in CFU/ml |
<0.01 |
<0.01 |
<0.01 |
<0.01 |
||
|
Particles, µm/mL |
<1 |
<1 |
<1 |
<1 |
||
|
Endotoxin, EU/ml |
n/a |
n/a |
<0.001 |
<0.001 |
||
|
Flow Rate, L /min |
1 |
1 |
0,6 |
0,6 |
||
|
Type 2 Water |
||||||
|
Applications |
Rinsing lab glassware, supplying autoclaves and ultrapure water systems, preparing and diluting buffers, reagents, and tissue culture media. |
|||||
|
Pure water production at 15°C, L/h |
3, 6, or 12 |
3, 6, or 12 |
3, 6, or 12 |
3, 6, or 12 |
||
|
Resistivity at 25°C, MΩ.cm |
15-10 10-15 |
15/10 |
5/10 |
15/10 |
||
|
Conductivity, µS/cm |
0.067 - 0.1 |
0.067 - 0.1 |
0.067 - 0.1 |
0.067 - 0.1 |
||
|
Ideal for your molecular biology, microbiology and analytical chemistry applications : |
||||||
|
Type 1 Applications |
Type 2 Applications |
|||||
|
Cell and tissue culture |
Rinsing lab glassware |
|||||
|
PCR, DNA sequencing |
Supplying general lab equipment |
|||||
|
Electrophoresis, TOC Measurements, IC |
Preparing and diluting buffers, reagents, and media |
|||||
|
HPLC, GC-MS, ICP-MS, AA |
||||||
|
Specifications |
||||||
|
Model |
Smart2Pure 3,6 |
Smart2Pure 12 |
Storage Reservoirs |
|||
|
30 L |
60 L |
|||||
|
Dimensions H x W x D |
545 x 305 x 390 mm |
545 x 305 x 300 mm |
603 x 380 mm |
914 x 380 mm |
||
|
( 22 x 12 x 15 ) in |
( 22 x 12 x 12 ) in |
( 24 x 15 ) in |
( 36 x 15 ) in |
|||
|
Product Weight kg (lbs) w/o water |
21 ( 46 ) |
20 ( 44 ) |
8 ( 18 ) |
15 ( 33 ) |
||
|
Ship Dimensions H x W x D |
706 x 455 x 430 mm |
706 x 455 x 430 mm |
706 x 455 x 430 mm |
940 x 410 x 495 mm |
||
|
( 28 x 18 x 17 ) in |
( 28 x18 x 17 ) mm |
( 28 x 18 x 17 ) in |
( 37 x 16 x 19 ) in |
|||
|
Shipping Weight kg ( lbs.) |
24-27 ( 52-60 ) |
22-25 ( 48-55 ) |
10 ( 22 ) |
17 ( 37 ) |
||
|
Required feed water quality |
||||||
|
Source |
Tap water |
|||||
|
TDS |
>500 ppm |
|||||
|
Turbidity |
> 1 N.T.U |
|||||
|
pH Range |
4 – 11 |
|||||
|
Temperature,°C |
Feb-35 |
|||||
|
Pressure, psi ( bar ) |
1.4 - 87 ( 1 - 6 ) |
|||||
|
Order Informations |
||||||
|
System Options |
Permeate flow at |
Smart2Pure |
Smart2Pure UV |
Smart2Pure UF |
Smart2Pure UV/UF |
|
|
15°C |
Standard |
|||||
|
Smart2Pure System |
3 L /hr |
50129869 |
50129872 |
50129870 |
50129688 |
|
|
Systems include RO/pretreatment cartridge, an ultrapure polisher cartridge, sterile 0.2 µM filter, and UV lamp and/or UF filter where applicable. 3 and 6 L /hr version also include an internal 6L tank with vent filter. |
6 L /hr |
50129873 |
50129885 |
50129874 |
50129887 |
|
