Bath Circulator MaXircu CH-8,CH-12,CH-22,CH-30 Daihan Scientific

Specification

Models

MaXircu

MaXircu

MaXircu

MaXircu

CH-8

CH-12

CH-22

CH-30

Bath Volume

8 Lit.

12 Lit.

22 Lit.

30 Lit.

Pump

Max Flow Rate : 16 Lit./min, ( Available to Control 1~5Level Flow Rate ), Max Pressure : 5 psi, Max Lift : 2.8 m

Temp. Range & Accuracy

Room Temp＋5 ℃~ 250 ℃, ±0.1 ℃

Temp. Resolution

0.1 ℃-Display, 0.5 ℃-Control

Temp. Uniformity & Probe

±0.2 ℃, PT100

Heating Power

1.0 kW

1.5 kW

2.2 kW

2.5 kW

Heat-up Time

50 min. to 100 ℃

External Circulation Nozzle

id.10.5 / od.12.5 mm

Timer & Alarm

99 hr 59 min ( Delay & Continuous run ), Error status & Timer-end

Display

Digital LCD with Back - Light Function

Controller

Digital Fuzzy Controller with Jog - Dial Knob ( Turn＋Push )

Safety Circuit

Over-Temp./-Current protection, Sensor Error & Low Level Detection

Material

Stainless steel ( ＃304 )-Internal,  Powder Coated steel-External,

50mm Thickness Ceramic Fiber-Insulation

Lid

included Stainless-steel Flat Lid ( with Insulation ), Optional Dome Lid,

Drain Valve

Ball Valve

Dimension ( W x D x H )

Effective Space

180 × 130 × h155

250 × 130 × h155

340 × 250 × h155

340 × 250 × h200

Internal ( mm )

180 × 320 × h155

250 × 320 × h155

340 × 440× h155

340 × 440 × h200

External ( mm )

303 × 443 × h569

373 × 443 × h569

463 × 563 × h569

463 ×563 × h614

Packing Size (mm)

470 × 400 × h500

470 × 400 × h500

600 × 490 × h500

600 × 490 × h500

& Gross Weight

19 kg

21 kg

23 kg

37 kg

Electrical Reqts.

1 Phase, AC 120 V, 60 Hz or  AC 230 V, 50 / 60 Hz

Cat. No.

230V

DH.WCH00408

DH.WCH00412

DH.WCH00422

DH.WCH00430

120V

DH.WCH00508

DH.WCH00512

DH.WCH00522

DH.WCH00530
