| Features | |||||||
| Compact ( 5.7 x 2.9 x 1.5 in. / 14.5 x 7.4 x 3.8 cm ) and lightweight ( 13.1 oz. / 370 g ) | |||||||
| Rugged, highly water-resistant design... Continuous LCD shows simultaneous gas concentrations for 5 gases | |||||||
| Integral concussion-proof enclosure for the most rugged environments | |||||||
| Integral motorized pump option for remote sampling ( optional ) | |||||||
| Two power options: three AA alkaline batteries or a rechargeable battery pack | |||||||
| Provides 95 dB alarm tone and two bright wide-angled alarm bars | |||||||
| Equipped with internal vibrating alarm for high noise areas | |||||||
| Multi-language support in English, French, German, Spanish and Portuguese | |||||||
| Three backlight options: standard-activates in low light ( auto ), in alarm ( auto ) and reactivates on-demand; alarm only-activates in alarm conditions and reactivates on-demand; stealth mode | |||||||
| Four alarm levels: instantaneous Low and High Alarm for all gases; TWA ( time weighted average ) and STEL (short term exposure limit) for toxic gases | |||||||
| Simple automatic calibration procedure; compatible with BW MicroDock II system | |||||||
| Records TWA, STEL and maximum exposures to gas and displays readings on command | |||||||
| User selectable field options include: confidence beep, pass code protection, latching alarm, calibration due date and "SAFE" display function, stealth mode, selectable ppm resolution for some gases ( e.g. SO2 0.1 ppm ) | |||||||
| Full function self-test of: sensor, battery and circuit integrity; and audible/visual alarms | |||||||
| Specifications | |||||||
| Gas | : | Measuring range | Resolution | TWA | STEL | LOW | HIGH |
| O2 | : | 0-30.0% | 0.1 | N/A | N/A | 19.5 | 22.5 |
| CO | : | 0-999 ppm | 1 | 35 | 200 | 35 | 200 |
| H2S | : | 0-100 ppm | 1 | 10 | 15 | 10 | 15 |
| PH3 | : | 0-5.0 ppm | 0.1 | 0.3 | 1.0 | 0.3 | 1.0 |
| SO2 | : | 0-100 ppm | 0.1 | 2 | 5 | 2 | 5 |
| NO2 | : | 0-99.9 ppm | 0.1 | 2.0 | 5.0 | 2.0 | 5.0 |
| HCN | : | 0-30.0 ppm | 0.1 | 4.7 | 10.0 | 4.7 | 10.0 |
| Cl2 | : | 0-50.0 ppm | 0.1 | 0.5 | 1.0 | 0.5 | 1.0 |
| NH3 | : | 0-100 ppm | 1 | 25 | 35 | 25 | 50 |
| ClO2 | : | 0-1 ppm | 0.1 | 0.1 | 0.3 | 0.1 | 0.3 |
| O3 | : | 0-1 ppm | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
| PID | : | 0-999 ppm | 5.0 | 50 | 100 | 50 | 100 |
| LEL | : | 0-100% LEL | 1% | N/A | N/A | 10% | 20% |
| : | 0-5% v/v | ||||||
| Software. | |||||||
| Fleet Manager II allows you to conveniently manage your gas detectors. Data storage and analysis has never been so simple. With the same look and feel as Fleet Manager, Fleet Manager II allows users to download information directly from BW Technologies or the MicroDock II. | |||||||
| With improved functionality, users can : | |||||||
| Automatically create accurate and user-friendly reports | |||||||
| Easily sort, format and graph data as well as view history | |||||||
| Archive and share data easily, including databases | |||||||
