| Features |
| Smaller and over 50 % lighter than competitive instruments |
| Water-resistant design in an integral concussion-proof enclosure |
| Continuous LCD shows simultaneous gas concentrations for five gases |
| 0 - 1000 ppm measurement of VOCs ( Volatile Organic Compounds ) |
| Integral motorized pump option for remote sampling |
| Two power options: AA alkaline or rechargeable hot-swappable battery pack |
| Provides 95 dB alarm tone and two bright wide-angled alarm bars |
| Equipped with internal vibrating alarm for high noise areas |
| Multi-language support in English, French, German, Spanish, and Portuguese |
| Three backlight options: standard- activates in low light ( auto ), in alarm ( auto ) and reactivates on-demand; alarm only- activates in alarm conditions and reactivates on-demand; stealth mode |
| Four alarm levels: instantaneous Low and High Alarm for all gases; TWA ( time-weighted average ) and STEL ( short-term exposure limit) for VOCs and toxic gases |
| Simple automatic calibration procedure; compatible with BW MicroDock II automatic test and calibration station |
| Records TWA, STEL, and maximum exposures to gas and displays readings on command |
| User selectable field options include: PID correction factor, language selection, confidence beep, span level, set TWA/STEL calculation choice, set calibration due date, pass code protection, latching alarm, 'SAFE' display function, stealth mode, and selectable ppm resolution for some gases (e.g. SO2 0.1 ppm) |
| Full function self-test of: sensor, battery and circuit integrity; and audible/visual alarms |
| Specifications |
| Gas |
: |
Measuring range |
Resolution |
TWA |
STEL |
LOW |
HIGH |
| O2 |
: |
0-30.0% |
0.1 |
N/A |
N/A |
19.5 |
22.5 |
| CO |
: |
0-999 ppm |
1 |
35 |
200 |
35 |
200 |
| H2S |
: |
0-100 ppm |
1 |
10 |
15 |
10 |
15 |
| PH3 |
: |
0-5.0 ppm |
0.1 |
0.3 |
1.0 |
0.3 |
1.0 |
| SO2 |
: |
0-100 ppm |
0.1 |
2 |
5 |
2 |
5 |
| NO2 |
: |
0-99.9 ppm |
0.1 |
2.0 |
5.0 |
2.0 |
5.0 |
| HCN |
: |
0-30.0 ppm |
0.1 |
4.7 |
10.0 |
4.7 |
10.0 |
| Cl2 |
: |
0-50.0 ppm |
0.1 |
0.5 |
1.0 |
0.5 |
1.0 |
| NH3 |
: |
0-100 ppm |
1 |
25 |
35 |
25 |
50 |
| ClO2 |
: |
0-1 ppm |
0.1 |
0.1 |
0.3 |
0.1 |
0.3 |
| O3 |
: |
0-1 ppm |
0.1 |
0.1 |
0.1 |
0.1 |
0.1 |
| PID |
: |
0-999 ppm |
5.0 |
50 |
100 |
50 |
100 |
| LEL |
: |
0-100% LEL |
1% |
N/A |
N/A |
10% |
20% |
