| Features | ||||
| Oxygen Sensor with an 3 Year Warranty | ||||
| Designed for cold weather performance | ||||
| IP68 rating which protects from total dust ingress and from immersion over 1m | ||||
| IntelliFlash verifies operation and compliance to both the user and supervisor | ||||
| Built-in datalogging & event logging | ||||
| Tamper-proof, one button operation | ||||
| Powered by a rechargeable lithium polymer battery | ||||
| Continuous LCD shows real-time gas concentrations | ||||
| Compact and lightweight design makes it comfortable to wear | ||||
| Water-resistant | ||||
| Simple automatic calibration procedure; compatible with BW MicroDock II automatic test and calibration station | ||||
| Full function self-test of sensor, battery status, circuit integrity and audible/visual alarms on start up | ||||
| Bright wide-angled visual alarm bars | ||||
| Equipped with internal vibrating alarm for high noise areas | ||||
| Built-in concussion-proof boot | ||||
| Multi-language support in English, French, German, Spanish and Portuguese | ||||
| Conveniently manage your fleet using Fleet Manager II | ||||
| BW Gasalert MicroClip X3 Specifications | ||||
| Gas | : | Measuring Range | Resolution | |
| H2S | : | 0 to 100 ppm | 1 ppm | |
| CO | : | 0 to 500 ppm | 1 ppm | |
| O2 | : | 0 to 30.0 % | 0.1 % | |
| Combustible gases | : | 0 to 100 % LEL | 1 % | |
| : | 0 to 5.0 % v/v | 0.1 % | ||
| Alarm setpoints for all sensors are user adjustable. Setpoints are automatically displayed during instrument start up. | ||||
| Size | : | 4.4 x 2.4 x 1.2 in / 11.3 x 6.0 x 3.1 cm | ||
| Weight | : | 6.7 oz. / 190 g | ||
| Temperature | : | -4 to 122 °F / -20 to 50 °C | ||
| Humidity | : | 0 % to 95 % RH ( non-condensing ) | ||
| Alarms | : | - Visual, vibrating, audible ( 95 dB ) | ||
| : | - Low, high, STEL, TWA, OL ( over limit ) | |||
| Tests | : | Audible/visual alarms on activation, sensors, battery and circuitry ( continuous ) | ||
| Typical Battery Life | : | 18 hours; recharges in less than 6 hours | ||
| User Options | : | Confidence beep | ||
| : | Set STEL interval | |||
| : | Sensor on/off | |||
| : | Latching alarms | |||
| : | Safe display mode | |||
| : | Stealth mode | |||
| : | Calibration lock | |||
| : | Auto zero on start up | |||
| : | O2 auto calibration on start up | |||
| : | Set bump test interval | |||
| : | Force bump test when overdue | |||
| Ratings | : | EMI/RFI: Complies with EMC Directive 2004/108/EC IP 66 | ||
| Certifications and Approvals | : | Class I, Div. 1, Gr. A, B, C, D | ||
| : | ATEX: II 1 G | |||
| : | Ex ia IIC T4 Ga | |||
| : | IECEx: Ex ia IIC T4 Ga | |||
| : | European Conformity | |||
