| Features |
| Smallest, lightest four gas monitor |
| Built-in datalogging & event logging |
| IP66/67 rating for moisture/dirt protection |
| Rechargeable battery pack for longer battery life |
| Compatible with SamplerPak pump for remote sampling |
| IntelliFlash verifies operation and compliance to both the user and supervisor |
| Tamper-proof, one button operation |
| Compatible with the Sampler motorized remote sampling pump |
| Equipped with internal vibrating alarm for high noise areas |
| Powered by a lithium polymer battery |
| Multi-language support in English, French, German, Spanish and Portuguese |
| Conveniently manage your fleet using Fleet Manager II |
| Specifications |
| Gas |
: |
Measuring Range |
| H2S |
: |
0-100 ppm |
| CO |
: |
0-500 ppm |
| O2 |
: |
0-30.0 % |
| Combustible gases |
: |
0-100 % LEL |
| |
: |
0-5.0 % v/v |
| Alarm setpoints for all sensors are user adjustable. Setpoints are automatically displayed during instrument start up. |
| Specifications |
| Size |
: |
4.4 x 2.4 x 1.2 in. / 11.3 x 6.0 x 3.1 cm |
| Weight |
: |
6.7 oz. / 190 g |
| Temperature |
: |
-4 to +122 °F / -20 to +50 °C |
| Humidity |
: |
0 % - 95 % RH ( non-condensing ) |
| Alarms |
: |
- Visual, vibrating, audible ( 95 dB ) |
| |
: |
- Low, high, STEL, TWA, OL ( over limit ) |
| Tests |
: |
Audible/visual alarms on activation, sensors, battery and circuitry ( continuous ) |
| Typical battery life |
: |
18 hours; recharges in less than 6 hours |
| User options |
: |
Confidence beep |
| |
: |
Set STEL interval |
| |
: |
Sensor on/off |
| |
: |
Latching alarms |
| |
: |
Safe display mode |
| |
: |
Stealth mode |
| |
: |
Calibration lock |
| |
: |
Auto zero on start up |
| |
: |
O2 auto calibration on start up |
| |
: |
Set bump test interval |
| |
: |
Force bump test when overdue |
| Ratings |
: |
EMI/RFI : Complies with EMC Directive 2004/108/EC IP 66 |
| Certifications & approvals |
: |
Class I, Div. 1, Gr. A, B, C, D |
| |
: |
ATEX: II 1 G |
| |
: |
Ex ia IIC T4 Ga |
| |
: |
IECEx: Ex ia IIC T4 Ga |
| |
: |
European Conformity |
