Centrifuge PLC Series Gemmy

Model

PLC-01

Approval

ISO 9001,ISO 13485,CE,GMP,FDA

Spec

Diamension

270 x 270 x 250 mm

Timer

Mechanical 60 mins

Power indicator

LED lamp

Rotor

A-0415 for 4 pcs x 15 ml ( 10 ml ) testing tubes

Optional

Automatic lid shutout safety device

Optional

NON CE motor

Model

PLC-02

Spec

Dimension

270 x 270 x 250 mm

Timer

Mechanical, 60 min.

Power Indicator

LED Lamp

Rotor

Fixed angle

Fixed speed

Available upon request

Safety shutout device

Option

capacity

6 tubes of 10 or 15ml

Speed

1000 – 4000 ( or 4500 rpm )

Quality, QMS Standard

ISO9001, ISO13485 CE, GMP, FDA

Model

PLC-03

Approval

CE,ISO,GMP,FDA

Spec

Dimension

270 x 270 x 250 mm

Timer

Mechanical , 60min

Power indicator

LED lamp

Rotor

A-0815 for 8 pcs x 15 ml ( 10 ml ) testing tubes

Speed

4500 rpm, Maximum

Model

PLC-012

Approval

CE.GMP,FDA,ISO9001 13485

Spec

Tachometer

Analog

Timer

Mechanical

Speed control

Analog

Safety lid lock

Yes

Brake

Electrical switch

Safety shutout

Yes

Dimension

310 x 360 x 310 mm

Motor Brush

80 W

Chamber

Stainless steel

Model

PLC-012E

Approval

CE,GMP,FDA,ISO 13485,ISO 9001

Spec

Tachometer

Analog

LED

Digital

Timer

Mechanical

Tachometer

LED digital

Timer

Digital 99 min.

Speed control

Analog

Microprocessor

Yes

Safety lid

Lock

Brake

Electrical switch

Safety shutout

Yes

Dimension

310 x 360 x 310 mm

Motor Brush

80 W

Chamber

Stainless steel
