| Specification | |||
| Product | HP130910-33Q | HP130914Q | HP130915Q |
| Temp. Range ( Metric ) | 540°C ( Max Temperature ) | 540°C ( Max Temperature ) | 540°C ( Max Temperature ) |
| Max. Temperature ( Metric ) | 540°C | 540°C | 540°C |
| Max. Container Size | 1L | 1L | 1L |
| Max. Sample Load | 15 lb. | 15 lb. | 15 lb. |
| Voltage | 220/240V | 100V | 120V |
| Top Plate Material | Ceramic | Ceramic | Ceramic |
| Surface Area (English) Heating | 4.25 x 4.25 in. | 4.25 x 4.25 in. | 4.25 x 4.25 in. |
| Surface Area (Metric) Heating | 10.8 x 10.8cm | 10.8 x 10.8cm | 10.8 x 10.8cm |
| Height (English) | 3.63 in. | 3.63 in. | 3.63 in. |
| Height (Metric) | 10cm | 10cm | 10cm |
| Length (English) | 10 in. | 10 in. | 10 in. |
| Length (Metric) | 25cm | 25cm | 25cm |
| Width (English) | 5 in. | 5 in. | 5 in. |
| Width (Metric) | 13cm | 13cm | 13cm |
| Hertz | 50/60Hz | 50/60Hz | 60Hz |
| Certifications/Compliance | cCSAus, CE Marked | cCSAus | cCSAus |
| Dimensions (L x W x H) | 10 x 5 x 3.63 in.(25 x 13 x 10cm) | 10 x 5 x 3.63 in.(25 x 13 x 10cm) | 10 x 5 x 3.63 in. (25 x 13 x 10cm) |
| Electrical Requirements | 220/240V 50/60Hz | 100V 50/60Hz | 120V 60Hz |
| Type | Hotplates | Hotplates | Hotplates |
| Product Size | HP131220-33Q | HP131224Q | HP131225Q |
| Temp. Range (Metric) | 540°C (Max Temperature) | 540°C (Max Temperature) | 540°C (Max Temperature) |
| Max. Temp. (Metric) | 540°C | 540°C | 540°C |
| Max. Container Size | 4L | 4L | 4L |
| Max. Sample Load | 25 lb. | 25 lb. | 25 lb. |
| Voltage | 220/240V | 100V | 120V |
| Top Plate Material | Ceramic | Ceramic | Ceramic |
| Surface Area (English) Heating | 7.25 x 7.25 in. | 7.25 x 7.25 in. | 7.25 x 7.25 in. |
| Surface Area (Metric) Heating | 18.4 x 18.4cm | 18.4 x 18.4cm | 18.4 x 18.4cm |
| Height (English) | 3.88 in. | 3.88 in. | 3.88 in. |
| Height (Metric) | 10cm | 10cm | 10cm |
| Length (English) | 13 in. | 13 in. | 13 in. |
| Length (Metric) | 33cm | 33cm | 33cm |
| Width (English) | 8.25 in. | 8.25 in. | 8.25 in. |
| Width (Metric) | 21cm | 21cm | 21cm |
| Hertz | 50/60Hz | 50/60Hz | 60Hz |
| Certifications/Compliance | cCSAus, CE Marked | cCSAus | cCSAus |
| Dimensions (L x W x H) | 13 x 8.25 x 3.88 in.(33 x 21 x 10cm) | 13 x 8.25 x 3.88 in.(33 x 21 x 10cm) | 13 x 8.25 x 3.88 in.(33 x 21 x 10cm) |
| Electrical Requirements | 220/240V 50/60Hz | 100V 50/60Hz | 120V 60Hz |
| Type | Hotplates | Hotplates | Hotplates |
| Product Size | HP131530-33Q | HP131534Q | HP131535Q |
| Temp. Range (Metric) | 540°C (Max Temperature) | 540°C (Max Temperature) | 540°C (Max Temperature) |
| Max. Temp. (Metric) | 540°C | 540°C | 540°C |
| Max. Container Size | 6L | 6L | 6L |
| Max. Sample Load | 35 lb. | 35 lb. | 35 lb. |
| Voltage | 220/240V | 100V | 120V |
| Top Plate Material | Ceramic | Ceramic | Ceramic |
| Surface Area (English) Heating | 10.25 x 10.25 in. | 10.25 x 10.25 in. | 10.25 x 10.25 in. |
| Surface Area (Metric) Heating | 26 x 26cm | 26 x 26cm | 26 x 26cm |
| Height (English) | 4 in. | 4 in. | 4 in. |
| Height (Metric) | 10cm | 10cm | 10cm |
| Length (English) | 16.25 in. | 16.25 in. | 16.25 in. |
| Length (Metric) | 41cm | 41cm | 41cm |
| Width (English) | 11.38 in. | 11.38 in. | 11.38 in. |
| Width (Metric) | 29cm | 29cm | 29cm |
| Hertz | 50/60Hz | 50/60Hz | 60Hz |
| Certifications/Compliance | cCSAus, CE Marked | cCSAus | cCSAus |
| Dimensions (L x W x H) | 16.25 x 11.38 x 4 in.(41 x 29 x 10cm) | 16.25 x 11.38 x 4 in.(41 x 29 x 10cm) | 16.25 x 11.38 x 4 in.(41 x 29 x 10cm) |
| Electrical Requirements | 220/240V 50/60Hz | 100V 50/60Hz | 120V 60Hz |
| Type | Hotplates | Hotplates | Hotplates |
| Product Size | HP141920-33Q | ||
| Temp. Range (Metric) | 540°C (Max Temperature) | ||
| Max. Temp. (Metric) | 300°C | ||
| Max. Container Size | 4L | ||
| Max. Sample Load | 25 lb. | ||
| Voltage | 220/240V | ||
| Top Plate Material | Aluminum | ||
| Surface Area (English) Heating | 7.25 x 7.25 in. | ||
| Surface Area (Metric) Heating | 18.4 x 18.4cm | ||
| Height (English) | 3.88 in. | ||
| Height (Metric) | 10cm | ||
| Length (English) | 13 in. | ||
| Length (Metric) | 33cm | ||
| Width (English) | 8.25 in. | ||
| Width (Metric) | 21cm | ||
| Hertz | 50/60Hz | ||
| Certifications/Compliance | cCSAus, CE Marked | ||
| Dimensions (L x W x H) | 13 x 8.25 x 3.88 in. (33 x 21 x 10cm) | ||
| Electrical Requirements | 220/240V 50/60Hz | ||
| Type | Hotplates | ||
