CMUT Electromantles : Multiple Volume
The CMUT Electromantle is a multiple volume CMU Electromantle, able to accommodate round bottom flasks of between 250 ml to 1000 ml capacity. Its key features are otherwise the same as for the CMU Controlled Electromantles.
The CMUT Electromantle is used in wet chemistry to heat liquids in round bottom flasks. Its metal case is designed to remain "cool-to-the-touch" when in operation. For added safety, it has a grounded stainless steel earth screen covering the element and is double fused.
Key Features
Multiple volume round bottom flask capacity of between 250 ml to 1000 ml
Element temperatures up to 450 °C
"Cool-to-touch" outer casing
Built-in energy regulator
Indicator lamps for power and heater operation
Replaceable insulated heater cartridge
Rugged and easy to clean powder coated aluminium outer casing
Non-skid feet and support rod bracket ( but not including support rods )
Flexible coiled heating elements absorb shock, minimising the risk of flask breakage
Heating element is attached to a rigid thermal insulating cartridge to ensure maximum heat transfer and support
Added safety features such as a grounded earth stainless steel screen covering the heating element and double fuses
Technical Specification
Case material	Powder coated aluminum
Flask capacity	250 - 1000 ml
Max element temperature	450°C
Dimensions ( D x W x H )	220 x 220 x 170 mm
Shipping weight	1.5 kg
Ordering Information
Model	Capacity	Electrical Requirements
CMUT1000/CE	250 - 1000 ml	230V, 50/ 60 Hz , 300 W
CMUT1000/CEX1	250 - 1000 ml	115V, 50/ 60 Hz , 300 W
