CMUV Electromantles : For large volume flask and funnels
The CMUV Electromantles deliver the benefits of the CMU Electromantle, but do so for very large 60° funnels, as well as pear-shaped and round bottom flasks. This is achieved through a "V-shaped" design for the heating mantle, with funnels being accommodated through a bottom opening in the Electromantle base.
CMUV Electromantles have in built controls, heating control is provided by a built-in solid state Simmerstat energy regulator.
Key Features
Bottom opening accommodates 60° funnels of various diameters
Also accepts large capacity round bottom and pear-shaped flasks
Large capacity between 10 litres to 22 litres
Complete control of heating is provided by 3 separate electrical circuits that enable independent top, middle and bottom heating of flasks, each controlled with its own dial switch
Coiled heating element, suspended within a thermal insulating cartridge, provides maximum heat transfer and support
Replaceable insulated heater cartridge
Maximum element temperature 450 °C
Built-in energy regulator
Indicator lamps for power and heater operation
An easy to clean powder coated aluminum outer casing
"Cool-to-touch" outer casing
Non-skid feet and 3 support rod brackets ( does not include support rods )
Technical Specification
Model	CMUV10, CMUV12	CMUV20, CMUV22
No. of circuits	3 ( Top, Middle & Bottom )	3 ( Top, Middle & Bottom )
Max. Element Temperature	450 °C	450 °C
Dimensions ( D x W x H )	485 x 485 x 300 mm	485 x 485 x 300 mm
Shipping Weight	6 kg	8.5 kg
Ordering Information
Model	Flask/Funnel Capacity	Electrical Requirements	With Controller
CMUV10/CL	10 L	230v 50/ 60Hz, 2000 w	Yes
CMUV10/CLX1	10 L	115v 50/ 60Hz, 2000 w	Yes
CMUV12/CL	12 L	230v 50/ 60Hz, 2000 w	Yes
CMUV12/CLX1	12 L	115v 50/ 60Hz, 2000 w	Yes
CMUV20/CL	20 L	230V 50/ 60Hz, 3000 w	Yes
CMUV20/CLX1	20 L	115v 50/ 60Hz, 3000 w	Yes
CMUV22/CL	22 L	230V 50/ 60Hz, 3000 w	Yes
CMUV22/CLX1	22 L	115v 50/ 60Hz, 3000 w	Yes
