CON 450 Eutech Instruments
Specifications
Product	Description
Conductivity
Range	0 to 200 mS
Resolution	0.01 µS to 0.1 mS
Accuracy	±1 % full scale
Calibration	Auto/manual; 1 point/range
TDS
Range	0 to 200 ppt ( TDS factor 1.0 )
Resolution	0.01 ppm to 0.1 ppt
Accuracy	±1 % full scale
Calibration	Manual; 1 point/range
Salinity
Range	0 to 50 ppt
Resolution	0.01
Accuracy	±1 % full scale
Calibration	Manual; 1 point
Temperature
Range	-10.0 to 110.0 ºC ( 14.0 to 230.0 ºF )
Resolution	0.1 ºC/ºF
Accuracy	±0.5 ºC; ±0.9 ºF
Calibration	Offset in 0.1 increments, ±10 ºC or ±18 ºF
Others
Display	Custom LCD with backlight
Memory	Stores up to 500 data sets
Output	USB or RS232
Real-Time Clock	Time and date stamp on calibration and stored data
Temp. Compensation	Automatic or manual from -10 to 110 ºC
Power	Two AA batteries ( included ), >300 hours ( without backlight ); AC adapter ( optional )
Dimensions	Meter : 7 7/8" x 3 1/8" x 2 1/4" ( 20 x 8.3 x 5.7 cm )
( L x W x H )	Boxed : 9 1/8" x 9 1/8" x 2 3/4" ( 23 x 23 x 7 cm )
Weight	Meter : 1 lb ( 0.5 kg )
	Boxed : 1.4 lb ( 0.7 kg )
Order Information
Order No.	Item
Meter
ECCONWP45003	CON 450 Meter & Electrode: Meter, conductivity cell ( K = 1.0 ), Grip-Clip™, two AA batteries
ECCONWP45003K	CON 450 Meter Kit: Meter, conductivity cell ( K = 1.0 ), Grip-Clip™, two AA batteries, hard carry case, USB cable, calibration solutions
Electrodes
ECCONSEN72W	Conductivity/ATC cell, glass body, K = 0.1
CONSEN91W	Conductivity/ATC cell, K = 1.0
CONSEN92W	Conductivity/ATC cell, epoxy, K = 10.0
Accessories
GRIPCLIP	Grip-Clip™
60x426401	Optional 100 / 240 VAC SMPS power adapter, 9 V, 6 W
MINIPHONEUSB	USB cable for 450 series, mini phone plug to USB
30x427301	RS232 cable for 450 series, mini phone plug to RS232 9-pin (F)
ECCON84BT	84 μS conductivity standard, 480 mL
ECCON1413BT	1413 μS conductivity standard, 480 mL
ECCON1288BT	12.88 mS conductivity standard, 480 mL
ECCON1118BT	111.8 mS conductivity standard, 480 mL
