Corning Digital Stirring Hotplates PC-420D & PC-620D

Description

Pyroceram top

Digital display blinks when set temperature and stirring speeds are reached

Temperature accuracy within ±2°C

Stirring speeds at ±5% of the chosen setting

Hot top inidicator warns if unit is plugged in or too hot to touch

Angled front panel minimizes damage from spills

Specification

Model

PC-420D

PC-620D

Temp. range

Ambient +5 - 550 °C

Temp. accuracy

±2 °C

Material, top

Pyroceram

Top plate size

12.7 x 17.8 cm

25.4 x 25.4 cm

Dimensions

10.8 x 19.7 x 28 cm

11.75 x 19.7 x 39.1 cm

Stir range

60-1150 rpm

Stirring accuracy

±5 %

Display

Digital

Power Supply

230 V/50 Hz

Code No.

Description

6795-PR

Temperature Probe

440129

Support Rod, SS, 2 pcs

440140

Clamp/Bosshead

440141

Holding Rod, SS
