CyberScan PCD 650 Multiparameter Eutech Instruments
Specifications
Product Specification	Description
pH Range	-2.000 to 20.000 pH
Resolution & Accuracy	0.1/0.01/0.001 pH & ±0.002 pH
No. of pH Calibration Points	1 ( Offset ) to 6 points
pH Buffer Options	USA, NIST, DIN, PWB, Custom
mV Range	±2000.0 mV
Resolution & Accuracy	0.1 mV & ±0.2 mV
Ion Concentration Range	0.001 to 19900
Resolution & Accuracy	2 or 3 digits & ±0.5 % FS ( mono ); 1 % FS ( div )
No. of Ion Calibration Pts	Up to 8
Conductivity Range	.. to 500 mS/cm
Resolution & Accuracy	0.05 % FS & ±1 % FS + 1 LSD
Cell Constant	0.010 to 10.000
Temperature Coefficient	Linear & Pure
TDS Range	.. to 500.0 ppt
Resolution & Accuracy	0.05 % FS & ±1 % FS +1 LSD
Salinity Range	0 to 80 ppt
Resolution & Accuracy	0.05 % FS & ±1 % FS +1 LSD
Temperature Range	-10.0 to 110.0 °C / 14.0 to 230.0 °F ( Meter )
Resolution & Accuracy	0.1 °C/°F & ±0.5 °C/ ±0.9 °F
Temperature Compensation	Automatic / Manual ( 0 to 100 °C )
Memory	500 Data Sets with Date/Time stamping & Security password protection
Output	IrDA Wireless Communications
Display	Multi-data Back-lit dot matrix; 7.2 cm ( H ) x 5.4 cm ( W )
Special Functions	Auto-Calibration; Data-logging options with time/date indexed,  GLP compliance; Simultaneous Display and measurement of 4 parameters; Cal-due alarm; pH slope/offset Display & Self-diagnostic
Power	4 X 1.5 V "AA" Alkaline batteries or 9 V DC adapter, 500 mA
Order Information
Order No.	Stock Code
ECPCWP65043K	01X430602
Item	Waterproof CyberScan PC 650 pH/ mV/ Ion/ Conductivity/ TDS/ Resistivity/ Salinity handheld meter with pH electrode ECFC252203B, 4-cell Conductivity probe, DAS software, power adapter & carrying kit set ( all probes comes with 3m long cable )
