CyberScan pH 620 Eutech Instruments
Specifications
Product Specification	Description
pH Range	-2.000 to 19.999 pH
Resolution & Accuracy ( ±1 LSD )	0.1/ 0.01/ 0.001 & ±0.002 pH
mV Range	±2000 mV
Resolution & Accuracy ( ±1 LSD )	0.1 mV & ±0.2 mV
Ion Range	0.001 to 19900
Units	ppm/ molar/ mgL
Resolution & Accuracy	2/ 3 digits & 0.5 % FS ( Monovalent ) / 1 % ( Divalent )
Temperature Range	-10.0 to 110.0 °C ( 14.0 to 230 °F C1248 )
Resolution & Accuracy	0.1 °C/ 1.0 °F
Temperature Compensation	Automatic / Manual ( 0 to 100 °C )
No. of Calibration Points	Up to 6 points
Cal Due Alarm	Yes ( Days - Max 30 )
pH Buffer Options	USA, NIST, DIN, PWB
Custom Buffer Calibration	Yes ( 2 to 5 )
Slope/ Offset Display	Yes ( Display + Icon )
Inputs	DC phono sockets, 8 pin connector, BNC
LCD Display	Back-lit Dot Matrix
Memory	500 data sets
Output	Yes ( IrDA/ RS232C )
Special Functions	Stability Indicator; Self-diagnostic; Non-Volatile Memory; Hold & Auto-Power Off after 20 minutes
GLP	Yes
Ingress Protection	IP67
Power	4 'AAA' x 1.4 V batteries or  9 VDC power adapter
Order Information
Order No.	Item
ECPHWP62042k	pH620 pH/mV/Ion Meter with pH Electrode, ATC Probe, Power Adapter & pH Carrying Kit Set
ECPHWPTEMO1J	Temperature Probe ATC
01X030132	Universal Power Adapter
ECADPTRM9M25	Adpater for RS232 Communication Cable: 9-pin male to 25-pin male connector.
01X447601	USB IrDA Interface Adapter
01X344202	RS232 ( LED ) Interface Adaptor
