Digital Hotplate with Stirrer, UC152D and US152D Stuart

Choice of top plate :

- Robust coated aluminium

- Chemically resistant ceramic

• Flashing "Hot" warning light, mains independent

• Digital display of hotplate surface temperature

• Compact space saving design

Stylish and economical general purpose hotplate stirrers designed with safety as well as performance in mind. The compact shape takes up less bench space and makes storage easier. The hotplate has a digital display of the hotplate surface temperature and can also be used in conjunction with the SCT1 digital contact thermometer to accurately control sample temperature.

The "Hot" warning light will flash whenever the plate temperature is above 50°C even when the hotplate is turned off and unplugged from the mains. Powerful magnets and motor give stirring speeds up to 2000rpm and is capable of mixing large volumes ( up to 15 litres *).

Model UC152D has a glass ceramic top which has excellent chemical resistance. The surface is easy to clean and the thermal properties allow very high plate temperatures while ensuring the edges stay cooler, reducing the chance of accidental burns. The white surface ensures good visibility of colour changes.

Model US152D has a robust aluminium/silicon alloy top plate for excellent heat transmission. The top plate has a thin ceramic coating for added chemical resistance. A 700W element gives rapid heating and ensures even temperature distribution across the whole surface of the plate.

Both models have an integral fitting for a retort rod and are supplied with 2 x 25 mm PTFE coated stir bars.

Specifications

Model

US152D

UC152D

Plate Material

Coated AluminiumSilicon

Glass ceramic

Plate Dimensions, mm

150 x 150

150 x 150

Digital display

Yes

Yes

Heated Area, mm

150 x 150

120 x 120

Heater Power, Watt

700

500

Max plate temp, °C

325

450

Stirrer Speed, rpm

100 - 2000

100 - 2000

Maximum Stirring Capacity, L *

15

15

Dimensions ( w x d x h ), mm

172 x 248 x 120

172 x 248 x 122

Net weight, kg

2.9

2.9

Electrical supply

230 V, 50 Hz, 750 W

230 V, 50 Hz, 550 W

IP Rating

32

32
