Digital Multi-point Magnetic Stirrer MS-MP4 & MS-MP8 Daihan Scientific

Specification

Number of Stirring Points & Models

4 ( 2 × 2 ) Stirring Points

8 ( 4 × 2 ) Stirring Points

“MS-MP4”

“MS-MP8”

Plate Size

210 × 300 mm

210 × 500 mm

Stirring Capacity ( H2O )

Max. 0.5 Lit. per Point

Distance between Stirring Points

100 mm

Speed Range

80 ~ 1,200 rpm

Motor Rating

16/9 W

Speed Control Resolution

5 rpm

Timer & Alarm

99 hr 59 min ( with Continuous run.), Error status & Timer-end

Display

Digital LCD with Back - Light Function

Controller

Digital Feedback Controller with Jog Shuttle Switch ( Turn+Push )

Stirring Bar

3 cm bar-included, Usable : up to 3 cm bar

Permissible Ambient Temp.

Ambient +5 ~ 50 ℃

Permissible Relative Moisture

85 %

Plate

Stainless steel ( ＃304 )

Body

Power Coated Steel

Dimension ( W × D × H )

210 × 300 × 65 mm

210 × 500 × 65 mm

Weight

2.5 kg

3.5 kg

Others

CE Certified, PL ( Product Liability ) Insurance

Storage Function ( RPM, Timer )

Locking Mode ( Jog - Shuttle Input Disabled ) Alarm ( Error Status and Timer – end )

Packing Size ( W x D x H )

330 × 300 × 180 mm

540 × 330 × 180 mm

& Gross Weight

6 kg

Power Consumption

20 W

Power Supply & Cord/ Plug*

Free Voltage ( 1 Phase, AC 80 ~ 240 V, 50 / 60 Hz )
