Digital Overhead Stirrer HS-T Daihan Scientific

Specification

Stirring Capacity & Models

Max. 10 Lit. ( H2O )

Max. 20 Lit. ( H2O )

“HS - 30T”

“HS - 100T”

Maximum Viscosity

10,000 mPas

50,000 mPas

Maximum Torque

85 Ncm

145 Ncm

Speed Range & Motor

200 ~ 3,000 rpm,  Direct Driven DC Motor

Motor Rating ( Input / Output )

83 / 75 W,  1/10 HP

130 /120 W,  1/6 HP

Timer & Alarm

99 hr 59 min ( with Continuous run.), Timer-end Alarm

Display

Digital LCD with Back - Light Function

Controller

Remote type Digital Feedback Controller with Jog Shuttle Switch

Max. Impeller Shaft Diameter

Φ8 mm

Permissible Temp. & Humidity

0 ~ 40 ℃, 80 %

Safety Device

Overload & Heat Protector for motor

Material

ABS and Aluminum

Dimension & Weight*

90 × 100 × h180 mm, 3 kg

90 × 100 × h180 mm, 3.8 kg

Packing Size & Gross  Weight

580 × 340 × h 230 mm, 5 kg

580 × 340 × h 230 mm, 8 kg

Power Consumption

75 W

120 W

Power Supply & Cord Plug**

1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
