Programmable Digital Rockers RK Daihan Scientific

Specification

Model

Platform Size : 290 × 200 mm

Platform Size : 300 × 300 mm

“RK- 1D”

“RK- 2D”

Dimensions (W × D × H)

Platform

290 × 200 mm

300 × 300 mm

Overall

290 × 240 × 150 mm

300 × 330 × 150 mm

Speed Range ( rpm )

5 ~ 50

Angle ( degree )

±6 or ±9 ( ±9 as Factory Default )

Motor

35W Geared DC Motor

Program Function

10 Steps, 6 Programs

Timer & Alarm

99 hr 59 min ( with Continuous run.),  Error status & Timer-end

Display

Digital LCD with Back - Light Function

Controller

Programmable Digital Feedback Controller with Jog - Shuttle Switch ( Turn+Push )

Safety Circuit

Overload Protector for motor

Platform

Included Platform ( 290 × 200 mm )

Included Platform ( 300 × 300 mm )

Others

CE Certified,  PL ( Product Liability ) Insurance

Smooth Start and Change of the Stirring Speed for Stable Running

Storage Function ( RPM, Timer ) Locking Mode ( Jog - Shuttle Input Disabled) Alarm ( Error Status and Timer - end )

Packing Dimension ( W × D × H )

450 × 350 × 250 mm

Gross Weight

7 kg

8 kg

Power Consumption

35 W

Power Supply & Cord Plug

Free Voltage ( 1 Phase, AC 80V~240 V, 50/60 Hz )
