Digital Tablet Hardness Tester 298 DGP Ethik Technology

Product description

Equipment developed to perform hardness measuring on pills, fer- tilizers, candies, animal food, pellets, etc

Portable and easy handling.

Technical Characteristics

Digital microprocessor with liquid crystal viewer ( LCD )

Applied force visualization in real time until tablet’s breaking point

Aluminum body and knob, polycarbonate structure and translucent acrylic sample protector

Clear test area for easy cleaning

Automatic shut down after 2 minutes of stand by.

Technical Specifications

Physical characteristics of compressed .

Maximum hardness of 30 Kgf, diameter or compression of até 30 mm and thickness of 12 mm

Resolução de leitura hardness

0.1

Resolutio of dimensional reading

0.1

Saída for retransmissão

4 to 20 mA

Hardness reading units ( manual seleção )

Kgf; N ou Lb ( pound )

Measured reading units ( EDTS only )

mm

Indicação Digital

TouchScreen colorful com 4 digits

Grau de proteção

IP 20

Disponível nas voltagens

110 ou 220 Vca

Plugue de Alimentação

3 pines NBR 14136

Durometer 298 ATTS and EDTS Information

Model

Long mm

Depth mm

Height mm

Weight Kg

Power W

ATTS & EDTS

415

360

 256

5

100
