Disintegration Tester 301 Ethik Technology

Product description

Disintegration testing determines whether tablets or capsules disintegrate within a defined period of time when placed in a liquid medium compliant with USP

Exterior : corrosion resistant treatment and epoxy powder coated

Stainless Steel ( AISI 304 ) basket rack

Technical Characteristics

Temperature control and reading through sensor PT100 with 0,1 ⁰C resolution

Run-time and temperature microprocessed control, digital LCD display, sound alarm for end of test warning.

Immersion heater and circulator module guarantees temperature stability of the water bath and no vibration

Simple operation and easy cleaning baskets and bath

Lift-out of the baskets is performed manually or automatically ( depending on model )

Acrylic water bath with frontal drain.

Available Disintegration Tester models

301/AC

Lift-out of the baskets is performed manually; 01, 03 or 06 simultaneously driven baskets

301/AUT

Lift-out of the baskets is performed automatically; 01, 03 or 06 simultaneously driven baskets

301/IND

Lift-out of the baskets is performed independently; 03 or 06 baskets

301/AUT IND

Lift-out of the baskets is performed automati- cally and independently; 03 or 06 baskets

Technical Specifications

Temp. range

Amb +5 °C to 50 ºC

Temp. control resolution

±0,1

Temp. uniformity at 37 ºC

±0,5

Digital Timer

Programmable up to 99 h

RPM

29 and 32 RPM.

Output

4 to 20 ma

Heating system

Stainless steel tubular resistance

Eletrical specs

110 V or 220 V 50 Hz/60 Hz

Protection grade

IP 20

Included Accessories & Components

Operational manual

RBC Calibration Certificate, for temperature controller

Connection for Data Logger ( 4 to 20 mA )/td>

Optional

IQ and OQ qualification protocols

This Equipment Attends American Pharmacopeia Specifications USP

Included Acessories

Racks

Glass Vessels

Baskets

Tester Tubers

Acrylic Disc

1

1

1

  6

  6

3

3

3

18

18

6

6

6

36

36

Information by Model 301 series

Racks

Width mm

Depth mm

Height mm

Electrical Specs W

Weight Kg

1

400

280

600

700

32

3

680

280

600

700

39

6

1200

280

600

1300

52
