Series ED | Drying and heating chambers Avantgarde. Line with natural convection


important characteristics
Temperature range: ambient temperature plus 15 °C to 300 °C
High temperature accuracy thanks to APT.line™ technology
Natural convection
Controller with LCD display
Electromechanical control of the exhaust air flap
2 chrome-plated racks
Stackable
Class 2 independent temperature safety device ( DIN 12880 ) with visual temperature alarm
Ergonomic handle design
USB port for recording data
Technical Data ED Series
Description	ED 56	ED 115	ED 260
Basic data
Interior volume [L]	57	114	255
Housing dimensions not incl. fittings and connections W x H x D [mm]	560 x 625 x 565	710 x 735 x 605	810 x 965 x 760
Interiors dimentions W x H x D [mm]	360 x 420 x 380	510 x 530 x 425	610 x 760 x 550
Performance Data Temperature
Temperature range ... [°C] above ambient temperature to [°C]	15-300	8-300	5-300
Temperature uniformity at 150 °C [± K ]	2,5	2,0	2,0
Temperature fluctuation at 150 °C [± K ]	0,4	0,4	0,7
Heating-up time to 150 °C [min]	45	60	50
Recover y time after 30 seconds door open at 150 °C [min]	25	20	25
Energ y consumption at 150 °C [ Wh/h]	180	250	390

Series FD \| Drying and heating chambers Avantgarde.Line with forced convection
important characteristics
Temperature range: ambient temperature plus 10 °C to 300 °C
High temperature accuracy thanks to APT.line™ technology
Forced convection
Controller with LCD display
Electromechanical control of the exhaust air flap
2 chrome-plated racks
Units up to 115 L are stackable
Class 2 independent temperature safety device (DIN 12880) with visual temperature alarm
Ergonomic handle design
USB port for recording data
Technical Data FD Series
Description	FD 56	FD 115	FD 260
Basic data
Interior volume [L]	60	116	259
Housing dimensions not incl. fittings and connections W x H x D [mm]	560 x 625 x 565	710 x 735 x 605	810 x 965 x 760
Interiors dimentions W x H x D [mm]	400 x 440 x 345	550 x 550 x 385	650 x 780 x 515
Performance Data Temperature
Temperature range 15 °C above ambient temperature to [°C]	300	300	300
Temperature uniformity at 150 °C [± K ]	1,7	1,7	1,9
Temperature fluctuation at 150 °C [± K ]	0,3	0,3	0,5
Heating-up time to 150 °C [min]	15	20	20
Recover y time after 30 seconds door open at 150 °C [min]	5	5	7
Energ y consumption at 150 °C [ Wh/h]	290	340	420

Series FED \| Drying and heating chambers Avantgarde.Line with forced convection and enhanced timer functions
important characteristics
Temperature range: ambient temperature plus 10 °C to 300 °C
High temperature accuracy thanks to APT.line™ technology
Adjustable fan speed
Controller with LCD display
Electromechanical control of the exhaust air flap
2 chrome-plated racks
Units up to 115 L are stackable
Class 2 independent temperature safety device (DIN 12880) with visual temperature alarm
Ergonomic handle design
Ethernet interface
USB port for recording data
Technical Data FD Series
Description	FED 56	FED 115	FED 260
Basic data
Interior volume [L]	60	116	259
Housing dimensions not incl. fittings and connections W x H x D [mm]	560 x 625 x 565	710 x 735 x 605	810 x 965 x 760
Interiors dimentions W x H x D [mm]	400 x 440 x 345	550 x 550 x 385	650 x 780 x 515
Performance Data Temperature
Temperature range 10 °C above ambient temperature to [°C]	300	300	300
Temperature uniformity at 150 °C [± K ]	1,4	1,2	1,6
Temperature fluctuation at 150 °C [± K ]	0,3	0,3	0,5
Heating-up time to 150 °C [min]	15	20	20
Recovery time after 30 seconds door open at 150 °C [min]	5	5	7
Energy consumption at 150 °C [ Wh/h]	290	340	420
