DS2 Indsci Docking Station For Ventis MX4

Specifications

PHYSICAL SPecifications

Warranty

Two-year warranty – DSX (Standalone) and DSX-L (Local Server)

Guaranteed For Life™ Program** – DSXi (Cloud-connected)

Instruments supported

GasBadge Pro, MX6 iBrid, SafeCore™Module, Tango TX1,Ventis™ MX4, Ventis™ Pro Series,Ventis™ LS

Dimensions

GasBadge Pro, Tango TX1: H: 22.7cm (8.92"); W: 16.9cm (6.65"); D: 27.3cm (10.75")

Ventis MX4, Ventis LS: H: 24.9cm (9.83"); W: 16.9cm (6.65"); D: 27.3cm (10.75")

MX6 iBrid: H: 25.3 cm (9.96"); W : 16.9 cm (6.65"); D: 27.3c m (10.75")

SafeCore™ Module: H:27.3cm (10.75"); W: 16.89cm (6.65"); D: 29.21cm (11.5")

Gas inlets

3-Port Version: One ”fresh” air port, two calibration gas ports

6-Port Version: One ”fresh” air port, five calibration gas ports

Pump flow rate

1.2 SCFH (550 mL / min)

Communication

10 / 100 Ethernet support, RJ-45 Category 5 Connection

Display

128 x 64 Dot Matrix LCD – Multilingual modes

English, Spanish, French, German and Portuguese***

PERFORMANCE Specifications

Operating temperature range

0 ºC to +50 ºC /32 ºF to 122 ºF

Operating humidity range

0% to 80% relative humidity ( RH ) up to 30ºC ( 86ºF ), decreasing linearly to 50% RH at 50ºC (122ºF)

External power supply ratings

Supply voltage : 100-240 VAC/12 VDC

Frequency range : 50-60 Hz

Current rating : 5A

Ordering Information

1. Ordering Information

Part Number

Description

Instrument Configurations

18109396-ABC

SafeCore™ Module

18109327-ABC

Ventis™ MX4, Ventis™ Pro Series

18109328-ABC

Ventis™ LS

18109329-ABC

MX6 iBrid™

18109330-ABC

Tango™ TX1

18109331-ABC

GasBadge® Pro

-ABC

A– DSX Mode: 0 = DSX Standalone; 1 = DSXi Cloud-connected; 2 = DSX-L Local Server;

B– Number of Gas Inlet Ports: 3 = 3 Ports; 6 = 6 Ports

C– Power Cord Type: 1 = North America; 2 = EU; 3 = AUS; 4 = UK

KITS*

18109400

DSX Standalone Kit: Tango TX1 (H2S)

18109401

DSX Standalone Kit: Ventis MX4 (LEL, CO, H2S, O2)

18109404

DSXi Cloud-connected Kit: Tango TX1 (H2S)

18109405

DSXi Cloud-connected Kit: Ventis MX4, Ventis Pro Series (LEL, CO, H2S, O2)

Accessories

18105684

iGas® Reader and Assembly, 3 foot (0.9 meter)

18109323

iGas® Reader and Assembly, 6 foot (1.8 meter)

18105924

5-Port Gas Regulator Manifold Clamp

17113887

Ethernet Cable, 5' (Cat5E network cable)

17113895

Ethernet Cable, 10' (Cat5E network cable)

17113903

Ethernet Cable, 25' ( Cat5E network cable )

17154813

3G / 4G Router

17113945

5-Port Ethernet Hub

18109406

DSX to DSXi Activation Certificate
