DuoFreez SMART Digital Ultra-Low Temp. Freezer Daihan Scientific

Specification

Capacity

350 Lit.

500 Lit.

600 Lit.

Freezing System

DuoFreezTM  System

Temp.

Range

-95 ℃~-65 ℃

at Room Temp. of 30℃ and Humidity of 70 %

Sensor

PT100

Compressor

Hermetic Type

Condenser Type

Block Condenser, No Pin, Filter Free Mechanism

Refrigerant

Natural ( CFC Free Refrigerant System )

Controller & Display

7″ Full Touch Screen TFT LCD ( Smart-LabTM  Controller )

Max. Q'ty of Racks

21 pcs of 11 ( 1 × 11 )-Placed Rack

30 pcs of 11 ( 1 × 11 )-Placed Rack

36 pcs of 11 ( 1 × 11 )-Placed Rack

& 3 pcs of 7 ( 1 × 7 )-Placed Rack

& 3 pcs of 7 ( 1 × 7 ) -Placed Rack

& 3 pcs of 7 ( 1 × 7 )-Placed Rack

Material

Internal

Stainless steel ( #304 )

External

Powder Coated steel Plate

Others

CE & RoHS Certified, PL ( Product Liability ) Insurance Touch-Screen TFT LCD Controller ( Smart-LabTM  Controller ) CFC-Free Refrigerants

Built in Standard Warning and Alarm Functions

RS232 Communication link, Remote Control Software

Chamber Dim.

( W x D x H )

Internal (mm)

1,050 × 470 × 665

1,500 × 470 × 665

1,800 × 470 × 665

External (mm)

1,690 × 895 × 1,155

2,140 × 895 × 1,155

2,440 × 895 × 1,155

Net Weight

230 kg

270 kg

310 kg

Packing Size ( W x D x H ) (mm)

1,900 × 1,100 × 1,400

2,300 × 1,100 × 1,400

2,600 × 1,100 × 1,400

& Gross Weight

310 kg

362 kg

402 kg

Power

Dual mode

398 Wh

474 Wh

507 Wh

Consumption

Eco. mode

352 Wh

373 Wh

458 Wh

Power Supply & Cord Plug

1 Phase, AC 120V, 60Hz or  AC 230V, 50 / 60Hz
