E9000 Transportable Emissions Analyzer E-Instruments
Features
Up to 9 Gas Sensors :
O₂, CO, NO, NO₂, SO₂, H₂S (Electrochemical) and CO₂, CxHy Hydrocarbons, High CO ( NDIR )
Low NOx and “True” NOx Measurements
Built–in High Efficiency Thermoelectric Chiller with Automatic Condensate Drain
Heated Probe Head & Sample Line
Software Package with USB & Bluetooth Interface
Blue Tooth Wireless Communications
CO Dilution Auto–Range for Measurements up to 10%
Automatic Long–Term Monitoring & Data Logging
Enhanced Internal Memory (16,000 Tests)
Full Color Graphic Display Screen
Built-In Printer with Non-Fading Paper
High Temperature Probes with Sintered Filter
Stack Gas Velocity with Pitot Tube
Temperature & Pressure Measurements
CO₂ %, Efficiency, & Excess Air Calculations
Transportable Heavy Duty Aluminum Carrying Case
Complies with USEPA CTM-030 & CTM-034 test methods
Specifications
Parameter	Sensor	Range	Resolution	Accuracy
O₂	Electrochemical	0 - 25 %	0.1 %	±0.2 % vol
CO				±8 ppm <200 ppm
H₂ compensated w/built-in NOx filter	Electrochemical	0 - 8000 ppm	1 ppm	±5 % rdg up to 2000 ppm
				±10 % rdg for >2000 ppm
CO diluted	Electrochemical	0.8 - 10.00 %	0.1 %	±10 % rdg
CO	NDIR	0 - 15.00%	0.1 %	±3 % rdg
CO₂	Calculated	0 - 99.9 %	0.1 %
CO₂	NDIR	0 - 50.0 %	0.1 %	±3 % rdg <8 %
				±5 % rdg <50 %
NO	Electrochemical	0 - 5000 ppm	1 ppm	±5 ppm <100 ppm
				±5 % rdg for >100 ppm
NO₂	Electrochemical	0 - 1000 ppm	1 ppm	±5 ppm <100 ppm
				±5 % rdg for >100 ppm
Low NO and/or Low NO₂	Electrochemical	0 - 100.0 ppm	0.1 ppm	±1.5 ppm <40 ppm
				±5 % rdg for <100ppm
Nox	Calculated	0 - 5000 ppm	1 ppm
SO₂	Electrochemical	0 - 5000 ppm	1 ppm	±5 ppm <100 ppm
				±5 % rdg for >100 ppm
Low SO₂	Electrochemical	0 - 100.0 ppm	0.1 ppm	±1.5 ppm <40 ppm
				±5 % rdg for <100ppm
CxHy ( HC )	NDIR	0 - 50,000 ppm	1 ppm	±50 ppm <2,500 ppm
				±2 % >2,500 ppm
H₂S	Electrochemical	0 - 500.0 ppm	0.1 ppm	±5 ppm <125 ppm
				±4 % rdg for <500ppm
Tair	Pt100	-4 to 248 °F	0.1 °F	±1 °F
		-20 to 120 °C	0.1 °C	±1 °C
Tgas	Tc K	-4 to 2280 °F	0.1 °F	±2 °F
		-20 to 1250 °C	0.1 °C	±2 °C
Differential Temp.	Calculated	-4 to 2280 °F	0.1 °F
		-20 to 1250 °C	0.1 °C
