EM Series Electromantles
The EM series Electromantles are manufactured to the highest quality in our UK manufacturing facility. Each mantle is made with extreme care and is hand sewn to assure its reliability, quality and safety. Maximum heat transfer to the sample is achieved by having excellent insulation around the cartridge and good flask coverage. All Electrothermal mantles go through the 'burn off' procedure at the end of the manufacturing process enabling use straight out of the box.
Designed with flexibility and ease of use in mind, the EM series heating mantle is a reliable workhorse for your heating applications in the laboratory. All EM Electromantles have a built-in energy regulator with indicator lamps for power and heater operation. All mantles have support rod clamps as an integral feature and incorporate a grounded earth screen and double fuses for added safety. Larger capacity products have multiple heating elements, enabling a more even and directed transfer of heat.
Key Features
Chemically resistant polypropylene outer casing
Use with round bottom flasks from 50ml to 5 litres
Unique ventilation system which allows outer casing to remain safe to touch
Maximum element temperature 450 °C
Built-in energy regulator
Model EM5000/CE has 2 circuits for upper and lower level heating
Replaceble insulated heater cartridge
Indicator lamps for power and heater operation
A chemically resistant polypropylene outer casing
A grounded earth screen and double fuses for extra safety
Supplied with bracket for 1.3cm diameter support rods ( but not including support rod rods )
Technical Specification
EM Model	EM0050, EM0100, EM0250	EM0500, EM1000	EM2000, EM3000, EM5000
Flask capacity	50 - 250 ml	500- 1000 ml	2000- 5000 ml
Material	Polypropylene outer case	Polypropylene outer case	Polypropylene outer case
Max element temperature	450 °C	450 °C	450 °C
Dimensions ( D x W x H )	260 x 175 x 127 mm	310 x 238 x 145 mm	400 x 350 x 190 mm
Shipping weight	0.78 kg	1.25 kg	2.58 kg
Ordering Information
Model	Capacity	Electrical Requirement
EM0050/CE	50 ml	230v 50/ 60Hz, 60 w UK and EU plug
EM0050/CEX1	50 ml	115v 50/ 60Hz, 70 w
EM0100/CE	100 ml	230v 50/ 60Hz, 60 w UK and EU plug
EM0100/CEX1	100 ml	115v 50/ 60Hz, 70 w
EM0250/CE	250 ml	230v 50/ 60Hz, 150 w UK and EU plug
EM0250/CEX1	250 ml	115v 50/ 60Hz, 150 w
EM0500/CE	500 ml	230v 50/ 60Hz, 200 w UK and EU plug
EM0500/CEX1	500 ml	115v 50/ 60Hz, 200 w
EM1000/CE	1000 ml	230v 50/ 60Hz, 300 w UK and EU plug
EM1000/CEX1	1000 ml	115v 50/ 60Hz, 300 w
EM2000/CE	2000 ml	230v 50/ 60Hz, 500 w UK and EU plug
EM2000/CEX1	2000 ml	115v 50/ 60Hz, 500 w
EM3000/CE	3000 ml	230v 50/ 60Hz, 500 w UK and EU plug
EM3000/CEX1	3000 ml	115v 50/ 60Hz, 500 w
EM5000/CE	5000 ml	230v 50/ 60Hz, 800 w UK and EU plug
EM5000/CEX1	5000 ml	115v 50/ 60Hz, 800 w
