Emergency Escape Breathing Apparatus EEBA AVON Protection

Preparedness for Sudden Emergencies.

The Avon-ISI EEBA provides fast emergency respiratory protection for escape from atmospheres that have suddenly become Immediately Dangerous to Life or Health ( IDLH ).

Uncomplicated Design Means No Time Is Wasted.

This Emergency Escape Breathing Apparatus is easy to use, allowing the wearer to begin escape in just seconds. In the event of an emergency: open the carrying pouch, turn the cylinder valve to the “ON” position, remove and don the hood, and egress to a safe environment. Instructions are printed clearly on the outside of the pouch for easy reference. The compact pouch contains the complete unit and can be carried around the waist, neck, or over the shoulder. The clear hood allows full peripheral vision and protection despite the wearer’s hair length, facial hair or glasses.

Refilling the Cylinder is Simple.

The EEBA cylinder valve incorporates the pressure reducer and valve into one assembly, providing an easy to use, easy to refill cylinder. The valve uses a special fill port that eliminates disconnecting from the cylinder each time you need to refill.

The EEBA is used for many applications including

• Chemical Plants

• Petroleum Plants

• Construction

• High-rise Dwellings

• Transportation

• Agriculture

• Institutions & Hotels

• Aviation & Aerospace

• Government

• Mining

Product Specifications

Model

EEBA 5

EEBA 10

Escape Duration

5 minutes

10 minutes

Weight

6.75 lbs.

10.25 lbs.

Flow Rate ( initial )

36 - 39 lpm

36 - 39 lpm

Cylinder Pressure

2216 psi

3000 psi

Cylinder Type

Aluminum

Aluminum

Hood Material

Polyurethane PVC

Polyurethane PVC
