Enerac-500 Gas Analyzer

Specification

Physical

Case

9.75” x 4” x 2.75” Aluminum case with

Magnetic support

Weight

3 lbs.

Probe

9” L x 3.8” OD ( other lengths available ) Inconel steel stack   probe. Probe housing connects to instrument via a 10 ft. Viton hose ( other lengths available ) and water trap and thermoelectric condenser. Maximum continuous temperature: 2000 F.

Electrical Power

Battery

4-6 VDC. Rechargeable NiMH (included) or 4 disposable AA alkaline cells. Approx. 6-8 hours operating time (1.5 hours with T’cooler)

AC Charger

120/240v. 60/50 hz. 9vdc output

Display

Four line by 16 character Liquid Crystal Display with backlight illumination.

Printer

Internal 2” thermal printer.

Data Storage

Internal

400 individually selectable buffers hold one complete set of measurements each in non-volatile memory. Buffer contents can be sent to printer or serial port. Data is stored by pressing the STORE key  or automatically on a periodic basis

Communications

Serial Port ( RS-232C port ) settings

9600,N,8,1 USB Port Bluetooth Wireless ( Class 1 – 100 m )

Fuels

15 Fuels

#2 Oil, #4 Oil, #6 Oil, Natural Gas, Anthracite, Bituminous, Lignite, Wood ( 50% H₂O ), Wood ( 0% H₂O ), Kerosene, Propane, Butane, Coke Oven Gas, Blast Furnace & Sewer Gas. Custom fuels available on request or by customer programming using ENERCOM software

Measured Parameters

Range

Resolution

Accuracy

Ambient Temp.

Type RTD

0-150˚F

1˚F or C

+/- 2˚F M

Stack Temp. ( Net )

0-2000˚F (1100˚C)

1˚F or C

+/- 2˚F M

Type K Thermocouple

Oxygen ( O₂ )

0-25%

0.1%

+/- 0.2% M

Electrochemical Cell

Carbon Monoxide ( CO )

0-500

1 PPM

+/- 0.2% M**

Electrochemical Cell

0-2000 or

0-20000PPM

Nitric Oxide ( NO )

0-300

0.1 PPM

+/- 0.2% M**

Electrochemical Cell

0-2000 or

1 PPM

0-4000 PPM

1 PPM

Nitrogen Dioxide ( NO₂ )

0-500 or

0.1 PPM

+/- 0.2% M**

Electrochemical Cell

0-1000 PPM

1 PPM

Sulfur Dioxide ( SO₂ )

0-2000 PPM

1 PPM

+/- 0.2% M**

Elecrochemical Cell

Combustibles

0-5%

0.1%

+/- 0.2%(CH4)M

Catalytic Sensor

Stack Draft

+10” to 40” WC

0.1˚ WC

+/- 0.2% M

Smoke Test

ASTMD method D2156

Measured Parameters

Range

Resolution

Accuracy

Combustion Efficiency

0-100%

0.1%

+/- 1%

Carbon Dioxide ( CO₂ )

0-40%

0.1%

+/- 2%

Excess Air

0-1000%

1%

+/- .2%

Oxides Of Nitrogen ( NOx )

0-800

+/- 4%

0-3000

0.1 PPM

0-5000 PPM

1 PPM

or other

1 PPM

Pounds / Million Btu

0-99.99 #/mBtu

0.01 #/B

+/- 2%

( CO, NO, NO₂, S0₂ )

Grams / Brake-HP-HR ( CO, NO, NO₂, SO₂ )

0-99.99/bhp-hr

0.01g/bhp-hr

+/- 2%
