Escape Hood NH15 AVON Protection

The Avon NH15™ CBRN Air Purifying Escape Respirator is the smallest and most compact escape hood on the market, approved to carry NIOSH and CE marking. Its low cost makes it ideal for police, emergency medical services and fire officers seeking immediate or emergency respiratory protection in a CBRN scenario

The NH15™ hood has a five year shelf life and provides a high level of respiratory, eye and face protection for a minimum of fifteen minutes. Made of clear material, the NH15™ not only protects against all airborne CBRN threats but also protects the face from liquid agent splashes

The clear material gives a non-threatening appearance, aids with recognition of the wearer and also allows for superior visual communication. Twin low-profile filters on a unique hinge system feature the latest filtration media which reduces breathing resistance and a front reflector makes it easier to identify colleagues in low light environments

Features & Benefits

Compact

* Low Profile Filters to reduce snagging

* Streamlined design

See and be Seen

* Clear range of vision

* Reflective label

Fit and Comfort

* Close fit filters

* Self-Adjusting Harness

* 3 sizes

Cost of Ownership

* No fit test requirements

* No replaceable parts

* No maintenance or inspections

Technical Spec

The NH15™ is specifically designed to meet the stringent requirements of both the NIOSH CBRN Air Purifying Escape Respirator ( APER ) Standard and Article 10 type-examination approval requirements to BS8468-3.2 : 2009 type-1, under the PPE Directive 89/686/ EEC for CE marking.

Protection Factor & Hood Performance

Breathing Zone ( Oronasal )

Greater than 2, 000

Head zone ( Ocular )

Greater than 150

Neck size ranger

330 - 558 mm ( regular )

Donning time

Less than 30 s

Re-breathing CO₂

Less than 2.0 %

Breathing Resistance

Inhalation at 85 lpm

Less than 50 mm H₂0

Exhalation at 85 lpm

Less than 10 mm H₂0

Barrier Performance ( Tested at ECBC )

GB

Greater than 30 minutes

HD

Greater than 30 minutes

Smartman Performance ( Tested at ECBC )

GB

Greater than 30 minutes

HD

Greater than 30 minutes

Filter Performance

P3/ P100 ( Less than 0.03 % )

Particulate Penetration

P100 ( Less than 0.03 % )

Packaging

Pack Size

6 " X 4 " X 3.4 " in ( 150 X 100 X 90 mm )

Packaging type

4 layer foil barrier bag surrounded by reinforced nylon carrier

Weight ( as carried )

1 lb 7 oz ( 625 g )

Packaged shelf life

5 years when stored between 5 ⁰F and 105 ⁰F

User instructions

3 language user guide supplied

Sizing

Extra Small

12 to 13 inches

Regular

13 to 18 inches

Large

18 to 22 inches

Training hoods are available on request

Typical Filter Performance Data

Challenge Concentration ( ppm )

Breakthrough Time ( minutes )

Hydrogen Sulfide

500 > 150 minutes

Ammonia

1250 > 20 minutes

Sulphur Dioxide

750 > 30 minutes

Cyclohexane

1300 > 35 minutes

Formaldehyde

250 > 45 minutes

Hydrogen Cyanide

470 > 45 minutes

Nitrogen Dioxide

100 > 45 minutes

Phosphine

150 > 45 minutes

Phosgene

125 > 45 minutes

Cyanogen Chloride

150 > 30 minutes

Approvals

NIOSH CBRN approved TC-14G-0302

PPE Directive 89/686/EEC for CE marking, Article 10 type-examination approval to BS8468-3.2 : 2009 type-1 : Certificate No. CEC 40136 A2
