Explosion-Proof Refrigerator Freezers Thermolyne

Description

Thermostat and compressor components are isolated within a vapor-proof enclosure

Electrical connections are hardwired to prevent sparking and accidental disconnection

Magnetic vinyl gaskets for positive door seal CFC-free insulation and refrigerant

Manual defrost

Explosion-Proof Refrigerator/Freezers

Specification

Product Size

10ECEETSA

10ECEETSV

Certifications/Compliance

UL listed meets NFPA 45 and 70

UL listed meets NFPA 45 and 70

Color

White

White

Control

Mechanical Dial Thermostat/Outside on Rear of Unit

Mechanical Dial Thermostat/Outside on Rear of Unit

Current

1.9 Amps/230 Watts

1.0 Amps/240Watts

Amperage

1.2 A

1.5 A

Capacity

10.1 Cubic Feet/286 Liters

10.1 Cubic Feet/286 Liters

Capacity ( English )

10.1 cu. ft.

10.1 cu. ft.

Capacity ( Metric )

286 L

286 L

Casters

2 Adjustable Feet In Front, 2 Fixed Pads In Rear

2 Adjustable Feet In Front, 2 Fixed Pads In Rear

Defrost

Ref: Automatic Defrost; Frz: Manual Defrost

Ref: Automatic Defrost; Frz: Manual Defrost

Compressor

Bottom Mounted

Bottom Mounted

Display

Temperature - none

Temperature - none

Door Count

2 ( 2 compartments )

2 ( 2 compartments )

Door Style

Hinged, Open Left to Right, Reversible

Hinged, Open Left to Right, Reversible

Exterior Finish

Enameled steel

Enameled steel

Dim ( L x W x H ) Exterior

28.6 x 23.63 x 59.75 in. ( 76.2 x 60 x 151.77 cm)

28.6 x 23.63 x 59.75 in. ( 76.2 x 60 x 151.77 cm )

Dim ( D x W x H ) Interior

Ref : 18.25 x 19.75 x 38.25 in.( 46.4 x 50.2 x 97.2 cm )

Ref : 18.25 x 19.75 x 38.25 in.( 46.4 x 50.2 x 97.2 cm )

Frz : 11.25 x 18 x 18.25 in. ( 28.6 x 45.7 x 46.3 cm )

Frz : 11.25 x 18 x 18.25 in. ( 28.6 x 45.7 x 46.3 cm )

Hertz

60 Hz

50 Hz

Interior Finish

ABS Plastic

ABS Plastic

Insulation

Polyurethane Foam

Polyurethane Foam

Model

10ECEETSA

10ECEETSV

Net Weight ( English )

120 lb.

120 lb.

Net Weight ( Metric )

54.5kg

54.5kg

Plug Type

None supplied

None supplied

Shipping Weight ( English )

150 lb.

150 lb.

Shelves

3 Adjustable Shelves, 1 Fixed Shelf, 1 Drawer, 4 Door Shelves

3 Adjustable Shelves, 1 Fixed Shelf, 1 Drawer, 4 Door Shelves

Refrigerant

R134a, 100 % CFC Free

R134a, 100% CFC Free

Shipping Weight ( Metric )

68 kg

68 kg

Temp. Range ( Metric )

Rfgr : 1° to 12°C; Frzr: -12° to -20°C

Rfgr : 1° to 12°C; Frzr: -12° to -20°C

Temp. Range ( Refrigerator )

1° to 12°C

1° to 12°C

Temp. Range ( Freezer )

-12° to -20°C

-12° to -20°C

Type

Explosion Proof Freezer/Refrigerator

Explosion Proof Freezer/Refrigerator

Voltage

115 V

240 V

Electrical Requirements

115 V/60 Hz

230 V/50 Hz

Wattage

83w

360w

Warranty

13 Months Parts and Labor

13 Months Parts and Labor

For Use With ( Application )

Indoor Cold Storage Of Materials In Class I, Division I Group C and D, Class I Zone 1 Group IIB Environments

Indoor Cold Storage Of Materials In Class I, Division I Group C and D, Class I Zone 1 Group IIB Environments

Typical Lifetime

10 Years

10 Years

Min. Clearance

2 in. On Sides, 2 in. At Back, 2 in. On Top

2 in. On Sides, 2 in. At Back, 2 in. On Top

Lighting

Interior - none

Interior - none

Temp. ( Setpoint )

Adjustable

Adjustable

Explosion-Proof Refrigerator

Specification

Product Size

20EREETSV

20ERCETSV

Access Security

Door Lock

Door Lock

Certifications/Compliance

UL listed meets NFPA 45 and 70

UL listed meets NFPA 45 and 70

Color

White

White

Control

Mechanical Thermostat/Outside, On Top Of Unit, In Blue Housing

Mechanical Thermostat/Outside, On Top Of Unit, In Blue Housing

Description

Explosion-Proof Refrigerator

Corrosion Resistant, Explosion-Proof Refrigerator

Current

2.0 Amps/186 Watts

2.5 Amps/600 Watts

Amperage

2.5 A

2.5 A

Capacity

20.9 Cubic Feet/591.82 Liters

20.9 Cubic Feet/591.82 Liters

Capacity ( English )

20.0 cu. ft.

20.0 cu. ft.

Capacity ( Metric )

566.34 L

566.34 L

Casters

Adjustable Leveling Feet

Adjustable Leveling Feet

Defrost

Manual Defrost

Manual Defrost

Compressor

Bottom Mounted

Bottom Mounted

Display

Temperature Display - None

Temperature Display - None

Door Count

1 ( 1 compartment )

1 ( 1 compartment )

Door Style

Hinged, Opens Left to Right, Non-Reversible

Hinged, Open Left to Right, Non-Reversible

Exterior Finish

Epoxy Coated Steel

Epoxy Coated Steel

Dim ( L x W x H ) Exterior

34 x 35.81 x 73.13 in. ( 86.4 x 90.95 x 186.1 cm )

35.81 x 34 x 73.13 in. ( 90.95 x 86.4 x 186.1 cm )

Dim ( D x W x H ) Interior

27.8 x 23.8 x 57.8 in. ( 70.49 x 60.3 x 146.7 cm )

23.8 x 27.8 x 57.8 in. ( 60.3 x 70.49 x 146.7 cm )

Hertz

50 Hz

50 Hz

Interior Finish

Epoxy Coated Steel

Epoxy Coated Steel

Insulation

Polyurethane Foam

Polyurethane Foam

Model

20EREETSV

20ERCETSV

Plug Type

No Cord Supplied

No Cord Supplied

Shipping Weight ( English )

283 lb.

230 lb.

Shelves

4 Fixed Shelves, 6 Fixed Door Shelves

4 Fixed Shelves

Refrigerant

R134a,100 % CFC Free

R134a,100 % CFC Free

Shipping Weight ( Metric )

128 kg

104.3 kg

Temp. Range ( Metric )

1° to 12 °C

1° to 12 °C

Type

Explosion Proof Refrigerator

Explosion Proof Refrigerator

Voltage

230 V

230 V

Electrical Requirements

230 V/50 Hz

230 V/50 Hz

Warranty

13 Months Parts and Labor

13 Months Parts and Labor

For Use With ( Application )

Indoor Cold Storage Of Materials In Class I, Division I Group C and D, Class I Zone 1 Group IIB Environments

Indoor Cold Storage Of Materials In Class I, Division I Group C and D, Class I Zone 1 Group IIB Environments

Typical Lifetime

10 Years

10 Years

Min. Clearance

3 in. On Sides, 3 in. At Back, 3 in. On Top

3 in. On Sides, 3 in. At Back, 3 in. On Top

Lighting

Interior - none

Interior - none

Temperature ( Setpoint )

Adjustable Set Point - Yes

Adjustable Set Point - Yes
