Fire Helmet LTX Bullard

Technical Specifications

Dimensions

12 ¾” L x 10” W x 6 ½” H

Outer Shell Material

Thermoplastic

Inner Shell Material

Nylon Impact Cap

Suspension

4-point nylon crown strap

Warranty

Date of Manufacture; five ( 5 ) years on shell, 10 years on non-electronic components

GE Ultem™ thermoplastic outer shell

The durable heat-resistant thermoplastic shell has color pigment molded throughout and edge beading that will not melt, drip or ignite when tested to NFPA, 1971-2013

M-PACT Shell

Superior protection is provided by Bullard’s patented M-PACT shell with SmartRidge design, providing increased protection while remaining lightweight.

Sure-Lock® ratchet headband

Sure-Lock is the top performing ratchet headband, made exclusively by Bullard. Comfort brow pad is removable and washable or replaceable.

Rip-stop Nomex® ear/neck protector

Heat-resistant and backed with two layers of fire-resistant cotton flannel for comfort and protection. Nomex is a heat and flame resistant fabric made by DuPont. Provides premium protection in high heat situations.

Four-point crown strap assembly

Comfortable suspension system for extra protection against impact.

4” faceshield

Rugged, optically correct faceshield eliminates distortion and reduces eye stress and fatigue.

Nomex® chinstrap

Chinstrap with quick release buckle is comfortable and fire resistant.

Quick-Attach Blade System

The easiest way to quickly change out face protection; offered exclusively by Bullard

Scotchlite® reflective stripes

Highest quality reflective material available; retains reflectivity to 500 ºF ( 260 ºC ). No burning, cracking or peeling.

Stainless steel D-ring

Large, durable D-ring allows you to hang your helmet on virtually any size hook.

Three position ratchet height adjuster ( not shown )

The height adjuster is the base of our 12-point comfort system. Adjust to ride high, low, or somewhere in the middle for a custom fit.

TrakLite® Integrated Lighting

Available with Bullard TrakLite helmet lighting. Featuring multiple forward-facing, long lasting, bright LED lights, TrakLite is integrated into the helmet design for excellent weight balance and illumination. Added safety features include the rear buddy indicator light, long battery life ( uses four AAA batteries ) and easy on/off operation. Select models can also be retrofitted to include TrakLite.

LTX Deluxe Helmet System

• Black inner shell ( R929 )

• Sure-Lock ratchet suspension ( R624 )

• Black rip-stop Nomex ear/neck protector ( R721 )

• Quick-Release buckle chinstrap ( R145 )

• Removable fire-resistant cotton brow pad ( R634 )

• Quick-Release/postman slide chinstrap ( R141 )

• Edge beading

• Leather ratchet cover ( R160 )
