FoodALYT MBS-SBS L Micro & Standard Kjeldahl Block Digestion Units Fully Automatic Lift

Nitrogen Determination acc. to Kjeldahl

FoodALYT MBS 400 L Micro and Standard Kjeldahl Block Digestion Units Fully Automatic Lift

FoodALYT SBS 2000 L Micro and Standard Kjeldahl Block Digestion Units Fully Automatic Lift

FoodALYT MBS 400L, SBS 5000L

The Block Digestion Systems of the L series are equipped with a fully automatic lift. This relieves the user of handling the heavy sample unit and hot chemicals. The software allows for a fully automatc digestion process. After an individually programmable cooling and suction time, the fume hood is raised into the final position. The programming allows for individually adaptable temperature profiles and starting times.

Extremely simple and fast programming per one-button operation.

Menu designed in various languages.

10 freely configurable programmes for block temperature and digestion time.

Applications storable.

High power heater and extraction hood with exhaust gas collector.

Digestion vessels 100, 250 and 400 ml

RS 232-interface.

CE-conform and certified.

Items Supplied

All Block Digestion Units are delivered as complete systems, incl. digestion vessels, rack and extraction hood

Technical Data

Field of Application

FoodALYT MBS 160

For a small number of samples and low sample volumes.

FoodALYT MBS 400

For a small number of samples and low sample volumes.

FoodALYT SBS 800

For a small or average number of samples.

FoodALYT SBS 2000

For a large number of samples.

Technical Data

Mains supply

230 V, 50 Hz

Temp.-control range

up to 450 °C, digitally adjustable

Time-setting range

0 to 999 minutes, digitally adjustable

Programmes

10

Display

LCD

Interface

RS232

Order Informations

Type

No. Of places

Vessels (ml)

Power (W)

Size (W x D x H)

Weight (kg)

PU

Order No.

FoodALYT MBS 160

16

100

1000

43 x 46 x 77 cm

approx. 23

1

4700111

FoodALYT MBS 400

40

100

2000

43 x 46 x 77 cm

approx. 33

1

4700112

FoodALYT SBS 800

8

250

1000

43 x 46 x 77 cm

approx. 23

1

4700004

FoodALYT SBS 2000

20

250

2000

48 x 52 x 77 cm

approx. 33

1

4700005
