Forma 88300V -86°C Upright Ultra-Low Temp.Freezers Thermolyne
Product Size	88300V
Capacity ( English ) Shelf	125 lb.
Backup Systems	CO2 or LN2 Optional
Capacity ( Metric ) Shelf	303 kg
2 ml Vial Capacity per Freezer	30000
Access Security	KeyLock Standard, Padlock Compatible, Key Card Optional
Chart Recorder	7-day ink or inkless Optional
Certifications/Compliance	cULus, CE listed
Data Outputs	RS-485, 4-20 mA, dry contacts - standard
Description	Capacity : 14.9 cu. ft. ( 420.9 L ); Holds 300 boxes; 230 V/50 Hz
Amperage	9.5 A
Capacity	14.9 cu. ft., 421 L
Capacity ( English )	14.9 cu. ft.
Capacity ( Metric )	421 L
Display	Touch Screen LCD
Dim ( L x W x H ) Exterior	37.6 x 27 x 78 in. ( 96 x 69 x 198 cm )
Dim ( D x W x H ) Interior	28.3 x 17.8 x 51.2 in. ( 72 x 45 x 130 cm )
Hertz	50 Hz
Holds	300 boxes
Insulation	Vacuum Panel and Water Blown Foam
Plug Type	European
Shipping Weight ( English )	667 lb.
Shelves	3
Product Name	Forma
Shipping Weight ( Metric )	303 kg
Temp. Range	-50° to -86 °C
Temp. Range ( Metric )	-50 °C to -86 °C
Type	Ultra Low Freezer, Upright
Voltage	230 V
Doors	Single
Door Opening Recovery	13 min.
Electrical Requirements	230 V 50 Hz
Footprint ( English )	7.05 sq. ft.
Energy Usage	15.3/17 kW-hr/day
Health Monitoring	On Screen,Log File
Footprint ( Metric )	0.65 sq. meters
Inner Doors	4
Interior	Painted Steel - Standard, Stainless-steel - Optional
Line Voltage Indicator	Line voltage and Buck/Boost
Operating Modes	High Performance or Energy Efficiency
On-Board Datalogging	Standard
Peak Variation at -80C	+5.5/-6.4 °C
Regulatory Approvals	CE
Smart View Compatibility	SmartView Compatible
Setpoint Security	Standard - Individual user names and passwords
Vial to Energy Ratio	2.36 watts/100 mL vials ( box )
Vial to Footprint Ratio ( English )	4.255 vials/sq. ft
Vial to Footprint Ratio ( Metric )	46.154 vials/cu. m
Voltage Compensation	Buck/Boost
Warm up Time -80 C to -50C	213 min.
Weight ( English )	667 lb.
Weight ( Metric )	303 kg
Water Cooled	Optional
Warranty	Warranty varies by country, please contact us for details
Product Line	Forma
