Laboratory Chamber Furnaces RWF Carbolite Gero |
|||
|
Model RWF 11/5, RWF 11/13, RWF 11/23 |
|||
|
Model RWF 12/5, RWF 12/13, RWF 12/23 |
|||
|
Technical Specifications |
|||
|
Model |
RWF 11/5 |
RWF 11/13 |
RWF 11/23 |
|
Max temp ( °C ) |
1100 |
1100 |
|
|
Max continuous operating temp ( °C ) |
1000 |
1000 |
|
|
Volume ( litres ) |
5 |
13 |
|
|
Heat-up time ( mins ) |
10 |
11 |
|
|
Dimensions Internal H x W x D ( mm ) |
130 x 160 x 250 |
195 x 210 x 325 |
220 x 260 x 400 |
|
Dimensions External H x W x D ( mm ) |
585 x 375 x 325 |
655 x 435 x 610 |
705 x 505 x 675 |
|
Dimensions Ext with door open H x W x D ( mm ) |
800 x 375 x 325 |
905 x 435 x 610 |
990 x 505 x 675 |
|
Max power ( W ) |
2750 |
5000 |
9100 |
|
Holding power ( W ) |
680 |
1200 |
1800 |
|
Thermocouple type |
K |
K |
K |
|
Weight ( kg ) |
28 |
45 |
65 |
|
|
|||
|
Model |
RWF 12/5 |
RWF 12/13 |
RWF 12/23 |
|
Max temp ( °C ) 1100 |
1200 |
1200 |
1200 |
|
Max continuous operating temp ( °C ) 1000 |
1100 |
1100 |
1100 |
|
Volume ( litres ) 23 |
5 |
13 |
23 |
|
Heat-up time ( mins ) 13 |
12 |
13 |
15 |
|
Dimensions Internal H x W x D ( mm ) |
130 x 160 x 250 |
195 x 210 x 325 |
220 x 260 x 400 |
|
Dimensions External H x W x D ( mm ) |
585 x 375 x 485 |
655 x 435 x 610 |
705 x 505 x 675 |
|
Dimensions Ext with door open H x W x D ( mm ) |
800 x 375 x 485 |
905 x 435 x 610 |
990 x 505 x 675 |
|
Max power ( W ) |
2750 |
5000 |
9100 |
|
Holding power ( W ) |
820 |
1450 |
2100 |
|
Thermocouple type |
R |
R |
R |
|
Weight ( kg ) |
28 |
45 |
65 |
