Laboratory Chamber Furnaces VCF Carbolite Gero |
||
|
Model VCF 12/5, VCF 12/10, VCF 12/23, VCF 12/100 |
||
|
Technical Specifications |
||
|
Model |
VCF 12/5 |
VCF 12/10 |
|
Max temp ( °C ) |
1200 |
1200 |
|
Volume ( litres ) |
5 |
10 |
|
Heat-up time ( mins ) |
102 |
138 |
|
Dimensions Internal H x W x D ( mm ) |
260 x 155 x 130 |
365 x 180 x 155 |
|
Dimensions External H x W x D ( mm ) |
660 x 530 x 405 |
765 x 555 x 430 |
|
Configuration |
|
Floor-standing |
|
Max power ( W ) |
2500 |
3000 |
|
Holding power ( W ) |
900 |
1200 |
|
Thermocouple type |
R |
R |
|
Weight ( kg ) |
50 |
60 |
|
|
||
|
Model |
VCF 12/23 |
VCF 12/100 |
|
Max temp ( °C ) |
1200 |
1200 |
|
Volume ( litres ) |
23 |
100 |
|
Heat-up time ( mins ) |
125 |
150 |
|
Dimensions Internal H x W x D ( mm ) |
450 x 250 x 200 |
600 x 410 x 410 |
|
Dimensions External H x W x D ( mm ) |
850 x 600 x 500 |
1100 x 930 x 950 |
|
Configuration |
Floor-standing |
Floor-standing |
|
Max power ( W ) |
6000 |
15000 |
|
Holding power ( W ) |
2500 |
6000 |
|
Thermocouple type |
R |
R |
|
Weight ( kg ) |
130 |
200 |
