| Specifications |
| Size |
Pumped model |
7.6" H x 3.8" W x 2.6" D ( 193 x 96.5 x 66 mm ) |
| |
Diffusion model |
6.9" x 3.8" x 2.2" ( 175 x 96.5 x 56 mm ) |
| Weight |
Pumped model |
31 oz ( 880 g ) |
| |
Diffusion model |
26.8 oz ( 760 g ) |
| Sensors |
Over 25 intelligent interchangeable field-replaceable sensors including PID for VOCs, electrochemical sensors for toxic gases and oxygen, combustible LEL and NDIR sensors, and CO2 NDIR sensor |
| Battery Options, Runtime 8 and Recharge Time |
Rechargeable Li-ion ~12-hr. ( pumped )/18-hr. ( diffusion C8) runtime, < 6-hr. recharge time |
| |
Extended duration Li-ion ~18-hr. ( pumped )/28-hr. ( diffusion ) runtime, < 9-hr. recharge time |
| |
Alkaline adapter with 4 x AA batteries ~6-hr. ( pumped )/8-hr. ( diffusion ) runtime |
| Display |
Monochrome graphical LCD display ( 128 x 160 ) with backlighting. Automatic screen “flip” feature |
| Display Readout |
Real-time reading of gas concentrations; PID measurement gas and correction factor; Man Down Alarm on/off; visual compliance indicator; battery status; datalogging on/off; wireless on/off and reception quality. |
| |
STEL, TWA, peak, and minimum values |
| Keypad Buttons |
3 operation and programming keys ( Mode, Y/+, and N/- ) |
| Sampling |
Built-in pump or diffusion |
| Calibration |
Automatic with AutoRAE 2 Test and Calibration System³ or manual |
| Alarms |
Wireless remote alarm notification; audible ( 95 dB @ 30 cm ), vibration, visible ( flashing bright red LEDs ), and on-screen indication of alarm conditions |
| |
Man Down Alarm with pre-alarm and real-time remote wireless notification² |
| Datalogging |
Continuous datalogging ( 6 months for 5 sensors at 1-minute intervals, 24/7 ) |
| |
User-configurable datalogging intervals ( from 1 to 3,600 seconds ) |
| Communication and Data Download |
Data download and instrument set-up and upgrades on PC via desktop charging and PC comm. cradle, travel charger, or AutoRAE 2 Automatic Test and Calibration System ³ |
| |
Wireless Data and Alarm status transmission via built-in RF modem ( optional ) |
| Wireless Network |
ProRAE Guardian Real-Time Wireless Safety System or EchoView Host-based Closed-Loop System |
| Wireless Range ( Typical ) |
MultiRAE Lite to RAElink3 [ Z1 ] Mesh modem ~330 feet ( 100 meters ) |
| |
MultiRAE Lite to EchoView Host, RAEMesh Reader or RAEPoint ~660 feet ( 200 meters ) |
| |
MultiRAE Lite Wi-Fi to Access Point - 330 feet ( 100 meters ) |
| Operating Temperature |
-4° to 122°F ( -20° to 50°C ) |
| Humidity |
0% to 95% relative humidity ( non-condensing ) |
| Dust and Water Resistance |
IP-65 ( pumped ); IP-67 ( diffusion ) ingress protection rating |
| Safety Certifications |
CSA : |
Class I, Division 1, Groups A, B, C and D, T4 |
| |
|
Class II, Division 1, Groups E, F, G T85°C |
| |
ATE X : |
0575 II 1G Ex ia IIC T4 Ga |
| |
|
2G Ex ia d IIC T4 Gb with IR Sensor installed |
| |
|
I M1 Ex ia I Ma |
| |
IECEx : |
Ex ia IIC T4 Ga |
| |
|
Ex ia d IIC T4 Gb with IR Sensor installed |
| |
|
I M1 Ex ia I Ma |
| |
IECEx/ANZEx : |
Ex ia IIC T4 Ga |
| |
|
Ex ia d IIC T4 Gb with IR Sensor installed |
| |
|
Ex ia I Ma |
| EMI/RFI8 |
EMC directive : 2004/108/EC |
| Performance Tests |
LEL CSA C22.2 No. 152; ISA-12.13.01 |
| Languages |
Arabic, Chinese, Czech, Danish, Dutch, English, French, German, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, and Turkish |
| Warranty |
Two years on non-consumable components and catalytic LEL, CO, H₂S and O₂ sensors |
| |
One year on all other sensors, pump, battery, and other consumable parts |
| Wireless Frequency |
ISM license free band. IEEE 802.15.4 Sub 1GHz |
| |
Wi-Fi 802.11 b/g |
| Wireless Approvals |
FCC Part 15, CE R&TTE, Others⁴ |
| Radio Module |
Supports RM900A |
