| Genesys 10S UV-Vis Spectrophotometer Thermolyne | ||
| Model | GENESYS 10S UV-Vis | GENESYS 10S Vis |
| Optical Design | Dual-Beam – Internal Reference Detector | Single-Beam |
| Spectral Bandwidth | 1.8 nm | 5.0 nm |
| Light Source ( Typical Lifetime ) | Xenon Flash Lamp ( 5 years, 3 years guaranteed ) | Tungsten-Halogen Lamp ( 1000 hrs ) |
| Detectors | Dual Silicon Photodiodes | Silicon Photodiode |
| Wavelength Range | 190–1100 nm | 325–1100 nm |
| Accuracy | ±1.0 nm | |
| Repeatability | ±0.5 nm | |
| Slew Speed | 11,000 nm/min | |
| Scan Speed | Up to 3600 nm/min | |
| Data Interval for Scanning | 0.1, 0.2, 0.5, 1.0, 2.0, 5.0 nm | 1.0, 2.0, 3.0, 5.0 nm |
| Photometric | Up to 3.5 A at 260 nm | Up to 3.0 A at 340 nm |
| Linear Range | ||
| Display | -0.1 A; -1.5–125 %T; ±9999 C | -0.1–3.0 A; -0.3–125 %T; ±9999 C |
| Accuracy | ±0.005 A at 1.0 A | 0.5 % or ±0.005 A, |
| 0.010 A K₂Cr₂O₇ | Whichever is greater up to 2 A | |
| Noise | <0.00025 at 0.0 A; | <0.001 A at 0.0 A |
| <0.00050 at 1.0 A; | <0.002 A at 2.0 A | |
| <0.00080 at 2.0 A; | Peak-to-peak at 340 nm | |
| RMS at 260 nm | ||
| Drift | <0.0005 A /hr | 0.002 A /hr after warm-up |
| Stray Light | <0.08 %T at 220, 340 nm ( NaI, NaNO₂ ); | <0.1 %T at 340, and 400 nm |
| <1.0 %T 198–200 nm ( KCl ) | ||
| Display | Graphical with LCD backlight; 9.7 × 7.1 cm ( 3.8 × 2.8 in ) |
|
| Keypad | Sealed Membrane with tactile response keys | |
| Printer ( optional ) | 40 column Internal ( Text and graphics ); External USB printer ( HP PCL 3.0 and greater ) | |
| Connectivity | USB Type A port for USB memory device ( front panel ) | |
| USB Type B port for optional computer connectivity (rear panel) | ||
| USB Type A port for external printer ( rear panel ) | ||
| Dimensions | 30 W × 40 D × 25 H cm ( 11.8 × 15.7 × 9.8 in ) | |
| Weight | 8.6 kg ( 19 lbs ) | |
| Power Requirements | Selected Automatically 100–240 V; 50–60 Hz | |
| Ordering Information | ||
| GENESYS 10S UV-Vis Instruments | Part Number | |
| GENESYS 10S UV-Vis, US line cord | 840-208100 | |
| GENESYS 10S UV-Vis, with internal printer, US line cord | 840-208200 | |
| GENESYS 10S UV-Vis, Europlug & UK line cords | 840-209700 | |
| GENESYS 10S UV-Vis, with internal printer, Europlug & UK line cords | 840-209800 | |
| GENESYS 10S Vis Instruments | Part Number | |
| GENESYS 10S Vis, US line cord | 840-207900 | |
| GENESYS 10S Vis, with internal printer, US line cord | 840-208000 | |
| GENESYS 10S Vis, Europlug & UK line cords | 840-209500 | |
| GENESYS 10S Vis, with internal printer, Europlug & UK line cords | 840-209600 | |
| Supplied as Standard | ||
| • GENESYS 10S Series spectrophotometer | ||
| • 6-position cell changer | ||
| • Single cell holder | ||
| • 100–240 V Automatic Power supply | ||
| • AC power cord | ||
| • Spare fuses | ||
| • Protective plastic cover | ||
| • USB memory device | ||
| • USB cable | ||
| Note : Software is not included with the instrument and must be ordered separately. | ||
