Specifications
| Model | SH-DO-54NG | SH-DO-100NG | SH-DO-149NG |
| Air Circulation | Natural | ||
| Temp Range | Ambient +10 °C to 250 °C ( Ambient +18 °F to 482 °F ) | ||
| Time Range | 00.00 to 99 HR 59 MIN ( MIN SEC ) Selectable Digital Counter Timer | ||
| Temp & Time controller | Microprocess P I D Membrane Touch Digital controller | ||
| Heater Capacity | 800 W | 1200 W | 1800 W |
| Dimension Internal,mm | 380 × 340 × 420 | 480 × 400 × 530 | 555 × 450 × 600 |
| ( W x D x H ) inch | 14.96 x 13.39 x 16.54 | 18.90 x 15.75 x 20.87 | 21.85 x 17.72 x 23.62 |
| Dimension External,mm | 500 × 495 × 820 | 600 × 555 × 930 | 675 × 605 × 1000 |
| ( W x D x H ) inch | 19.69 x 19.49 x 32.28 | 23.62 x 21.85 x 36.61 | 26.57 x 23.82 x 39.37 |
| Weight | 44 Kg | 57.8 Kg | 74.4 Kg |
| Capacity | 54 L | 100 L | 150 L |
| Material Internal | Stainless Steel | ||
| Material External | Steel Plate With Powder Heating Coated | ||
| Shelves | 2 Supplied ( 12 Maximum ) | 2 Supplied ( 15 Maximum ) | 2 Supplied ( 17 Maximum ) |
| Electrical 120 V ,50/60 Hz, 1Φ | 7.3 A | 10.9 A | 16.4 A |
| Electrical 230 V ,50/60 Hz, 1Φ | 3.5 A | 5.2 A | 7.8 A |
